About the Runtboard PCB

Runtboard is an open source RP2040/RP2350 PCB design by Taran-the-Idiot, published on GitHub under the Custom license license. It is a 2-layer board measuring 370.7 × 129.5 mm, with 189 components from 14 distinct parts.

Its main chip is the Pico, from the RP2040/RP2350 family. By type, the board carries 99 diodes, 82 switches, 7 connectors and 1 IC.

It belongs with the keyboards designs in this gallery.

From the project

The header pins are there to make it easier for my wires to reach the pico without having to do funny stuff with the routing and microcontroller. It in a way gives me a third layer to use for connections, which made my life way easier when designing this board.

This is what my pcb looks like. It has a basic silkscreen but i drew all of it on kicad no figma or anything.

Runtboard, from the project README — From the project README

Main components on the Runtboard

Pico

Runtboard bill of materials (BOM)

189 components, 14 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	Pico	RPi_Pico_SMD_TH	U1
1	CONN_01X04_PIN Conn_01x04_Pin	MODULE_DM-OLED096-636	J1
1	CONN_01X14_MOUNTINGPIN Conn_01x14_MountingPin	PinHeader_1x14_P2.54mm_Vertical	J2
1	CONN_01X16_MOUNTINGPIN Conn_01x16_MountingPin	PinHeader_1x16_P2.54mm_Vertical	J3
1	CONN_01X05_MOUNTINGPIN Conn_01x05_MountingPin	PinHeader_1x05_P2.54mm_Vertical	J4
1	CONN_01X11_MOUNTINGPIN Conn_01x11_MountingPin	PinHeader_1x11_P2.54mm_Vertical	J5
1	CONN_01X04_MOUNTINGPIN Conn_01x04_MountingPin	PinHeader_1x04_P2.54mm_Vertical	J6
1	CONN_01X02 Conn_01x02	PinSocket_1x02_P2.54mm_Vertical	J7
71	SW_Push	SW_Cherry_MX_1.00u_PCB	SW1, SW2, SW3, SW4, SW5, SW6, SW7, SW8 +63
7	SW_Push	SW_Cherry_MX_2.00u_PCB	SW14, SW27, SW28, SW42, SW54, SW65, SW66
2	SW_Push	SW_Cherry_MX_2.75u_PCB	SW71, SW88
2	RotaryEncoder_Switch	RotaryEncoder_Alps_EC11E-Switch_Vertical_H20mm	SW86, SW87
82	D_Small	DIODE-1N4148	D1, D2, D3, D4, D5, D6, D7, D8 +74
17	LED	LED_D5.0mm	D45, D59, D60, D62, D75, D88, D89, D90 +9

Runtboard design files

The KiCad project lives in the Taran-the-Idiot/Runtboard repository on GitHub; these links point at the commit this page was built from.

LayoutPCB/PCB.kicad_pcb
SchematicPCB/PCB.kicad_sch
BOMPRODUCTION/PCB Fabs/PCB.kicad_pcb_bom.csv

Runtboard: common questions

What microcontroller does the Runtboard use?

The Runtboard is built around the Pico, from the RP2040/RP2350 family.

How big is the Runtboard PCB?

The Runtboard measures 370.7 × 129.5 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Runtboard?

189 components, from 14 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Runtboard design files?

From the Taran-the-Idiot/Runtboard repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Runtboard design in my own project?

It is published under Custom license, which limits how it may be reused; read the license before building on it.

Can I test firmware for the Runtboard without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
