Split flap units PCB layout, top view — open source board by tinkermax
Simulate this board

About the Split flap units PCB

Split flap units is an open source PCB design by tinkermax, published on GitHub under the CC-BY-4.0 license. It is a 2-layer board measuring 99.8 × 50.1 mm, with 23 components from 13 distinct parts.

Other key parts include the A4988. By type, the board carries 10 connectors, 9 capacitors and 4 modules.

It belongs with the displays & leds and robotics & motion designs in this gallery.

From the project

DIY mechanical spli-flap display

This is an alternate electronics and firmware for David Kingsman's Split-Flap Display.

MYNTPSERVER "au.pool.ntp.org" // Set the best fitting NTP server (pool) for your location MYTZ "AEST-10AEDT,M10.1.0,M4.1.0/3" // Set your time zone from https://github.com/nayarsystems/posixtz_db/blob/master/zones.csv

WORDNIKAPIKEY "" // Get your private key from https://developer.wordnik.com/ MINWORDLEN 9 // Specify minimum word length to fetch from Wordnik WORDUPDATESPERHOUR 1 // Set number of word updates from https://wordnik.com per hour. 0 will disable, else use an integer that results in an exact…

Split flap units, from the project README
From the project README

Main components on the Split flap units

A4988

Split flap units bill of materials (BOM)

23 components, 13 distinct parts — part numbers from the project's BOM.

QtyPartRefs
