Pmod sao
About the Pmod sao PCB
Pmod sao is an open source PCB design by TomKeddie, published on GitHub under the MIT license. It is a 2-layer board measuring 27 × 19 mm, with 3 components from 3 distinct parts.
By type, the board carries 1 crystal and 1 capacitor.
Pmod sao bill of materials (BOM)
3 components, 3 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Badgelife_sao_connector_v169bis | Badgelife-SAOv169-BADGE-2x3 | X1 |
| 1 | PMOD-Device-x1-Type-1-GPIO | PMOD_1X6_PTH_RA_PLUG | PMOD1 |
| 1 | 10uF | C_1206_HandSoldering | C1 |
Pmod sao design files
The KiCad project lives in the TomKeddie/prj-pmod repository on GitHub; these links point at the commit this page was built from.
Pmod sao: common questions
How big is the Pmod sao PCB?
The Pmod sao measures 27 × 19 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Pmod sao?
3 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Pmod sao design files?
From the TomKeddie/prj-pmod repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Pmod sao design in my own project?
Yes, under the terms of its MIT license, which TomKeddie chose for the repository.
