Module Panel (Faceplate FP1)

ytmytm·Pi1551-III·faceplates/Pi1551-III Module FP1/Pi1551-III Module FP1.kicad_pcb

Module Panel (Faceplate FP1) layout, top view — open source board by ytmytm

About the Module Panel (Faceplate FP1)

Module Panel (Faceplate FP1) is an open source PCB design by ytmytm, published on GitHub under the CERN-OHL-1.2 license. It is a 2-layer board measuring 100 × 35 mm, with 4 components from 1 distinct parts.

It belongs with the retro computing designs in this gallery.

From the project

Pi1551 in a Pi1541-III-style case: 1551 + TAP for Plus/4/C16, no 3D printing

A 1551 floppy emulator for Commodore C16, C116 and Plus/4, in the same mechanical and aesthetic package as the C64 Pi1541-III: Raspberry Pi 3–based, 1.3" OLED, rotary encoder, and stack of PCBs with faceplates.

This variant uses the Pi1551 firmware and connects to the computer via tcbm2sd (TCBM bus). It also adds a MiniDIN-7 port for TAP tape playback with a simple 1:1 male-to-male cable to the machine’s tape port.

Module Panel (Faceplate FP1), from the project README
From the project README

Module Panel (Faceplate FP1) bill of materials (BOM)

4 components, 1 distinct parts.

QtyPartRefs
4
Mounting_Pin
M1, M2, M3, M4

Module Panel (Faceplate FP1) design files

The KiCad project lives in the ytmytm/Pi1551-III repository on GitHub; these links point at the commit this page was built from.

Module Panel (Faceplate FP1): common questions

How big is the Module Panel (Faceplate FP1)?

The Module Panel (Faceplate FP1) measures 100 × 35 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Module Panel (Faceplate FP1)?

4 components, from 1 distinct parts. The full bill of materials is listed on this page.

Where can I download the Module Panel (Faceplate FP1) design files?

From the ytmytm/Pi1551-III repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Module Panel (Faceplate FP1) design in my own project?

Yes, under the terms of its CERN-OHL-1.2 license, which ytmytm chose for the repository.
