IOT-Memento-Design PCB layout, top view — open source ESP32 board by AID-IOT

About the IOT-Memento-Design PCB

IOT-Memento-Design is an open source ESP32 PCB design by AID-IOT, published on GitHub under the MIT license. It is a 2-layer board measuring 150 × 100 mm, with 9 components from 4 distinct parts.

Its main chip is the XIAO_ESP32C3, from the ESP32 family. Other key parts include the BMP280_Module. By type, the board carries 4 diodes, 3 resistors and 2 ICs.

It belongs with the iot & wireless and sensors designs in this gallery.

From the project

A keepsake PCB built at the AICTE IDEA Lab, Poornima College of Engineering. It is a working board as well as a memento: a Seeed XIAO ESP32C3 drives four WS2812B LEDs and reads a BMP280 pressure/temperature sensor, and serves the readings on a web page over WiFi. The front silksc

A keepsake PCB built at the AICTE IDEA Lab, Poornima College of Engineering. It is a working board as well as a memento: a Seeed XIAO ESP32C3 drives four WS2812B LEDs and reads a BMP280 pressure/temperature sensor, and serves the readings on a web page over WiFi. The front silkscreen carries the AICTE IDEA Lab and Poornima College logos.

1. Flash the board. Plug the XIAO into USB-C, then either:

IOT-Memento-Design, from the project README
From the project README

Main components on the IOT-Memento-Design

XIAO_ESP32C3BMP280_Module

IOT-Memento-Design bill of materials (BOM)

9 components, 4 distinct parts.

QtyPartRefs
1
XIAO_ESP32C3
U1
1
BMP280_Module
U2
4
WS2812B
D2, D3, D4, D5
3
R_US
R1, R2, R3

IOT-Memento-Design design files

The KiCad project lives in the AID-IOT/IOT-Memento-Design repository on GitHub; these links point at the commit this page was built from.

IOT-Memento-Design: common questions

What microcontroller does the IOT-Memento-Design use?

The IOT-Memento-Design is built around the XIAO_ESP32C3, from the ESP32 family.

How big is the IOT-Memento-Design PCB?

The IOT-Memento-Design measures 150 × 100 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the IOT-Memento-Design?

9 components, from 4 distinct parts. The full bill of materials is listed on this page.

Where can I download the IOT-Memento-Design design files?

From the AID-IOT/IOT-Memento-Design repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the IOT-Memento-Design design in my own project?

Yes, under the terms of its MIT license, which AID-IOT chose for the repository.

Can I test firmware for the IOT-Memento-Design without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
