About the Give-A-Star PCB

Give-A-Star is an open source ESP8266 PCB design by ANG13T, published on GitHub. It is a 2-layer board measuring 123.2 × 118.1 mm, with 14 components from 9 distinct parts.

Its main chip is the WeMos_D1_mini, from the ESP8266 family. Other key parts include the SSH1106. By type, the board carries 4 diodes, 2 ICs, 1 switch and 1 LED.

It belongs with the displays & leds designs in this gallery.

From the project

A Star PCB Board based on the ESP32-S2 and D1 Mini to teach the basics of soldering ⭐️🎁🎄

Right LED | LED Pin | ESP32-S2 Pin | D1 Mini Pin | | --- | --- | --- | | VIN | 7 | D5 | | GND | GND | GND |

Bottom Right LED | LED Pin | ESP32-S2 Pin | D1 Mini Pin | | --- | --- | --- | | VIN | 5 | D0 | | GND | GND | GND |

Left LED | LED Pin | ESP32-S2 Pin | D1 Mini Pin | | --- | --- | --- | | VIN | 11 | D7 | | GND | GND | GND |

Bottom Left LED | LED Pin | ESP32-S2 Pin | D1 Mini Pin | | --- | --- | --- | | VIN | 12 | D8 | | GND | GND | GND |

Give-A-Star, from the project README
From the project README

Main components on the Give-A-Star

WeMos_D1_miniSSH1106

Give-A-Star bill of materials (BOM)

14 components, 9 distinct parts.

QtyPartRefs
1
WeMos_D1_mini
U1
1
SSH1106
U2
6
R
.1, .2, .3, .4, .5, .6
1
BUTTON
SW1
1
LEFT
BOTTOMLEFT1
1
TOP
D1
1
RIGHT
D2
1
BOTTOMRIGHT
D3
1
LED
D4

Give-A-Star design files

The KiCad project lives in the ANG13T/Give-A-Star repository on GitHub; these links point at the commit this page was built from.

Give-A-Star: common questions

What microcontroller does the Give-A-Star use?

The Give-A-Star is built around the WeMos_D1_mini, from the ESP8266 family.

How big is the Give-A-Star PCB?

The Give-A-Star measures 123.2 × 118.1 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Give-A-Star?

14 components, from 9 distinct parts. The full bill of materials is listed on this page.

Where can I download the Give-A-Star design files?

From the ANG13T/Give-A-Star repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Give-A-Star design in my own project?

The repository has no license, so all rights stay with ANG13T. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Give-A-Star without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
