Arduino nano compatible shield

Aryan-git-byte·Arduino-nano-compatible-shield·kicad/Arduino-nano-compatible-shield.kicad_pcb

Arduino nano compatible shield layout, top view — open source AVR/Arduino board by Aryan-git-byte
Simulate this board

About the Arduino nano compatible shield

Arduino nano compatible shield is an open source AVR/Arduino PCB design by Aryan-git-byte, published on GitHub. It is a 2-layer board measuring 59 × 57.3 mm, with 25 components from 13 distinct parts.

Its main chip is the Arduino_Nano_Every, from the AVR/Arduino family. Other key parts include the L293D and LM7805_TO220. By type, the board carries 11 connectors, 8 capacitors, 2 ICs, 1 module, 1 buzzer and 1 diode.

It belongs with the robotics & motion, dev boards & breakouts and sensors designs in this gallery.

Arduino nano compatible shield, from the project README
From the project README

Main components on the Arduino nano compatible shield

L293DLM7805_TO220Arduino_Nano_Every

Arduino nano compatible shield bill of materials (BOM)

25 components, 13 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
L293D
U1
1
LM7805_TO220
U2
1
Arduino_Nano_Every
A1
3
Screw_Terminal_01x02
J1, J2, J3
5
Conn_01x03
J4, J5, J6, J9, J10
3
Conn_01x04
J7, J8, J11
1
Buzzer
BZ1
1
LED
D1
4
100 nF
C1, C5, C6, C8
2
470 uF
C2, C7
1
0.33 uF
C3
1
0.1 uF
C4
1
220 ohm
R1

Arduino nano compatible shield design files

The KiCad project lives in the Aryan-git-byte/Arduino-nano-compatible-shield repository on GitHub; these links point at the commit this page was built from.

Arduino nano compatible shield: common questions

What microcontroller does the Arduino nano compatible shield use?

The Arduino nano compatible shield is built around the Arduino_Nano_Every, from the AVR/Arduino family.

How big is the Arduino nano compatible shield?

The Arduino nano compatible shield measures 59 × 57.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Arduino nano compatible shield?

25 components, from 13 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Arduino nano compatible shield design files?

From the Aryan-git-byte/Arduino-nano-compatible-shield repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Arduino nano compatible shield design in my own project?

The repository has no license, so all rights stay with Aryan-git-byte. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Arduino nano compatible shield without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
