Pcb tile game tile panelized

bytesizedengineering·PCB-tile-based-game·Electrical Design/pcb_tile_game_tile_panelized/pcb_tile_game_tile_panelized.kicad_pcb

Pcb tile game tile panelized layout, top view — open source AVR/Arduino board by bytesizedengineering

About the Pcb tile game tile panelized

Pcb tile game tile panelized is an open source AVR/Arduino PCB design by bytesizedengineering, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 3.6 × 3.3 mm, with 42 components from 7 distinct parts.

Its main chip is the ATtiny3217-M, from the AVR/Arduino family. By type, the board carries 18 capacitors, 16 LEDs, 6 connectors, 1 IC and 1 resistor.

From the project

🧰 What You Need - Adafruit UPDI Friend - Arduino IDE - ATtiny3217 board - USB-C cable 1. Install MegaTinyCore 2. Select the Board 3. Connect the UPDI Friend 4. Select the Serial Port 5. Upload Code

Pcb tile game tile panelized, from the project README
From the project README

Main components on the Pcb tile game tile panelized

ATtiny3217-M

Pcb tile game tile panelized bill of materials (BOM)

42 components, 7 distinct parts.

QtyPartRefs
1
ATtiny3217-M
U2
3
Conn_01x05_Pin
J1, J3, J5
3
Conn_01x05_Socket
J2, J4, J6
16
SK6812MINI-E
LED1, LED2, LED3, LED4, LED5, LED6, LED7, LED8 +8
16
0.1uF
C1, C2, C3, C4, C5, C6, C7, C8 +8
2
1uF
C16, C17
1
DNP
R1

Pcb tile game tile panelized design files

The KiCad project lives in the bytesizedengineering/PCB-tile-based-game repository on GitHub; these links point at the commit this page was built from.

Pcb tile game tile panelized: common questions

What microcontroller does the Pcb tile game tile panelized use?

The Pcb tile game tile panelized is built around the ATtiny3217-M, from the AVR/Arduino family.

How big is the Pcb tile game tile panelized?

The Pcb tile game tile panelized measures 3.6 × 3.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Pcb tile game tile panelized?

42 components, from 7 distinct parts. The full bill of materials is listed on this page.

Where can I download the Pcb tile game tile panelized design files?

From the bytesizedengineering/PCB-tile-based-game repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Pcb tile game tile panelized design in my own project?

Yes, under the terms of its GPL-3.0 license, which bytesizedengineering chose for the repository.

Can I test firmware for the Pcb tile game tile panelized without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
