Raspberry
Chrismettal·flipper-zero-backpacks·pcb/Raspberry/Raspberry.kicad_pcb
About the Raspberry PCB
Raspberry is an open source PCB design by Chrismettal, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 66.4 × 48.1 mm, with 7 components from 7 distinct parts.
Other key parts include the PCF8523T. By type, the board carries 2 connectors, 1 IC, 1 crystal, 1 battery holder, 1 capacitor and 1 resistor.
It belongs with the dev boards & breakouts and iot & wireless designs in this gallery.
From the project
Backpack-style addon boards for the Flipper Zero!
This is a collection of addon boards for the Flipper Zero multi-tool in the style of a backpack that clips behind the Flipper!
Right now it features only an ESP32 wifi board, like the official wifi devboard, only formatted as a backpack and with an SD card slot fitted. There is also a protoboard to create your own designs in the same formfactor.
The backpack framework is designed to fit snugly to a Flipper inside its silicone case. Without a silicone sleeve, the board will have 2mm of space around the Flipper, which might be undesireable.

Main components on the Raspberry
Raspberry bill of materials (BOM)
7 components, 7 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | PCF8523T | SOIC-8_3.9x4.9mm_P1.27mm | U1 |
| 1 | 32.768KHZ 32.768kHz | Crystal_SMD_3215-2Pin_3.2x1.5mm | Y1 |
| 1 | Conn_01x10 | PinHeader_1x10_P2.54mm_Vertical | J26 |
| 1 | Conn_01x08 | PinHeader_1x08_P2.54mm_Vertical | J27 |
| 1 | C964850 CR927 (3V) | MY-927-01 CR927 Battery Holder | BT1 |
| 1 | C23630 2.2µF | C_0603_1608Metric | C1 |
| 1 | 1K | R_0603_1608Metric | R1 |
Raspberry design files
The KiCad project lives in the Chrismettal/flipper-zero-backpacks repository on GitHub; these links point at the commit this page was built from.
Raspberry: common questions
How big is the Raspberry PCB?
The Raspberry measures 66.4 × 48.1 mm, has 2 copper layers and is 1 mm thick.
How many components are on the Raspberry?
7 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Raspberry design files?
From the Chrismettal/flipper-zero-backpacks repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Raspberry design in my own project?
Yes, under the terms of its CC-BY-SA-4.0 license, which Chrismettal chose for the repository.
