About the PWR BRD by drharvey PCB

PWR BRD by drharvey is an open source ESP32 PCB design by dr-harvey, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 59.8 × 20 mm, with 22 components from 19 distinct parts.

Its main chip is the ESP32-S3-WROOM-1, from the ESP32 family. Other key parts include the MFRC522. By type, the board carries 7 resistors, 6 capacitors, 3 connectors, 3 diodes, 2 ICs and 1 switch.

It belongs with the iot & wireless, audio and power & battery designs in this gallery.

From the project

BailaBox - RFID enabled, ESP32-based music toy for kids that works with Home Assistant and network speakers.

BailaBox is an open-source, token-controlled music player interface built around an ESP32-S3, ESPHome and Home Assistant. Place a printed RFID token on the reader to start its assigned song or playlist, remove it to pause, and use the physical buttons and rotary encoder for playback and volume control.

This is a personal hobby project shared for other makers to study, modify and build. It is not a finished commercial product or a certified children's toy.

PWR BRD by drharvey, from the project README
From the project README

Main components on the PWR BRD by drharvey

ESP32-S3-WROOM-1MFRC522

PWR BRD by drharvey bill of materials (BOM)

22 components, 19 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP32-S3-WROOM-1
BQ24074RGT
Texas Instruments
U1
1
MFRC522
AP2112K-3.3
Diodes Incorporated
U2
1
USB_C_Receptacle_PowerOnly_6P
HOOYA
J1
1
JST PH 2.0 1x2P
BOOMELE(Boom Precision Elec)
J2
1
CONN_01X07_PIN
Conn_01x04
J3
1
C318884
master switch
G-Switch
SW1
1
SK6812
D5V0L1B2S9-7
Diodes Incorporated
D1
1
SK6812
LED_CHG
Foshan NationStar Optoelectronics
D3
1
SK6812
LED_PGOOD
Hubei KENTO Elec
D4
1
C19702
10 µF
Samsung Electro-Mechanics
C1
2
C14663
10 µF
Samsung Electro-Mechanics
C2, C3
2
100N
1 µF
Samsung Electro-Mechanics
C4, C5
1
100N
10 µF
Samsung Electro-Mechanics
C6
2
10K
5k1
UNI-ROYAL(Uniroyal Elec)
R1, R2
1
100K
1.5k
UNI-ROYAL(Uniroyal Elec)
R3
1
100K
1.8k
UNI-ROYAL(Uniroyal Elec)
R4
1
10K
10k
UNI-ROYAL(Uniroyal Elec)
R5
1
1.5k
UNI-ROYAL(Uniroyal Elec)
R6
1
330R
1.5k
UNI-ROYAL(Uniroyal Elec)
R7

PWR BRD by drharvey design files

The KiCad project lives in the dr-harvey/BailaBox repository on GitHub; these links point at the commit this page was built from.

PWR BRD by drharvey: common questions

What microcontroller does the PWR BRD by drharvey use?

The PWR BRD by drharvey is built around the ESP32-S3-WROOM-1, from the ESP32 family.

How big is the PWR BRD by drharvey PCB?

The PWR BRD by drharvey measures 59.8 × 20 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the PWR BRD by drharvey?

22 components, from 19 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the PWR BRD by drharvey design files?

From the dr-harvey/BailaBox repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the PWR BRD by drharvey design in my own project?

Yes, under the terms of its CC-BY-SA-4.0 license, which dr-harvey chose for the repository.

Can I test firmware for the PWR BRD by drharvey without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
