MicroBatteryCharger-Croquette

ElectronicCats·MicroBatteryCharger-Croquette·Hw/batteryCharger.kicad_pcb

MicroBatteryCharger-Croquette PCB layout, top view — open source board by ElectronicCats

About the MicroBatteryCharger-Croquette PCB

MicroBatteryCharger-Croquette is an open source PCB design by ElectronicCats, published on GitHub. It is a 2-layer board measuring 12.2 × 17.4 mm, with 13 components from 11 distinct parts.

Other key parts include the MCP73831-2-OT. By type, the board carries 4 connectors, 4 resistors, 2 diodes, 2 capacitors and 1 IC.

It belongs with the power & battery designs in this gallery.

From the project

Electronic Cats Micro for Lipo/Lion Battery Charger

This little lipo charger is so small and easy to use you can keep it on your desk or mount it easily into any project! A 3.7V/4.2V lithium polymer or lithium ion rechargeable battery into the connectors. There are two LEDs - one red and one green. While charging, the red LED is lit. When the battery is fully charged and ready for use, the green LED turns on. Seriously, it could not get more easy.

MicroBatteryCharger-Croquette, from the project README — From the project README

Main components on the MicroBatteryCharger-Croquette

MicroBatteryCharger-Croquette bill of materials (BOM)

13 components, 11 distinct parts.

Qty	Part	Footprint	Refs
1	MCP73831-2-OT	SOT-23-5	U1
1	Vcc	PinHeader_1x01_P2.54mm_Vertical	J1
2	GND	PinHeader_1x01_P2.54mm_Vertical	J2, J4
1	BAT	PinHeader_1x01_P2.54mm_Vertical	J3
2	LED	LED_0805_2012Metric_Pad1.15x1.40mm_HandSolder	D1, D2
1	10uF	C_0805_2012Metric_Pad1.15x1.40mm_HandSolder	C1
1	C	C_0805_2012Metric_Pad1.15x1.40mm_HandSolder	C2
1	330	R_0805_2012Metric_Pad1.15x1.40mm_HandSolder	R1
1	10k	R_0805_2012Metric_Pad1.15x1.40mm_HandSolder	R2
1	1k	R_0805_2012Metric_Pad1.15x1.40mm_HandSolder	R3
1	2.5K	R_0805_2012Metric_Pad1.15x1.40mm_HandSolder	R4

MicroBatteryCharger-Croquette design files

The KiCad project lives in the ElectronicCats/MicroBatteryCharger-Croquette repository on GitHub; these links point at the commit this page was built from.

LayoutHw/batteryCharger.kicad_pcb
SchematicHw/batteryCharger.kicad_sch

MicroBatteryCharger-Croquette: common questions

How big is the MicroBatteryCharger-Croquette PCB?

The MicroBatteryCharger-Croquette measures 12.2 × 17.4 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the MicroBatteryCharger-Croquette?

13 components, from 11 distinct parts. The full bill of materials is listed on this page.

Where can I download the MicroBatteryCharger-Croquette design files?

From the ElectronicCats/MicroBatteryCharger-Croquette repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the MicroBatteryCharger-Croquette design in my own project?

The repository has no license, so all rights stay with ElectronicCats. Use it as a reference, and ask the author before reusing the design.
