LCD PMOD
About the LCD PMOD PCB
LCD PMOD is an open source PCB design by goran-mahovlic, published on GitHub. It is a 2-layer board measuring 175.3 × 95.3 mm, with 166 components from 75 distinct parts.
Other key parts include the TPS61169DCKR, TPD4E001DRLR, AR1021-I/SS, M24C32-WMN6P and ADS8586SIPM. By type, the board carries 62 capacitors, 56 resistors, 18 connectors, 13 ICs, 7 diodes and 4 inductors.
It belongs with the displays & leds designs in this gallery.
Main components on the LCD PMOD
LCD PMOD bill of materials (BOM)
166 components, 75 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | TPS61169DCKR Texas Instruments | DCK5 | IC1 |
| 1 | TPD4E001DRLR Texas Instruments | DRL6 | IC2 |
| 1 | AR1021-I/SS Microchip | SOP65P780X200-20N | IC3 |
| 1 | M24C32-WMN6P STMicroelectronics | SOIC127P600X170-9N | IC4 |
| 1 | ADS8586SIPM ADS8586S Texas Instruments | LQFP-64_10x10mm_P0.5mm | U1 |
| 1 | REF5025AIDR REF5025AD Texas Instruments | SOIC-8_3.9x4.9mm_P1.27mm | U2 |
| 1 | DS90CF364AMTD Texas Instruments | SOP50P800X110-48N | U3 |
| 1 | DS90CF364AMTD DS90CF36B Texas Instruments | SOP50P800X110-48N | U4 |
| 1 | MC78L05ABDR2G MC78L05_SO8 ON Semiconductor | SOIC-8_3.9x4.9mm_P1.27mm | U5 |
| 1 | THS4032ID Texas Instruments | SOIC127P600X173-8N | U6 |
| 2 | THS4551IDGKT Texas Instruments | VSSOP-8_3.0x3.0mm_P0.65mm | U7, U8 |
| 1 | MC79L05ABDR2G MC79L05_SO8 ON Semiconductor | SOIC-8_3.9x4.9mm_P1.27mm | U9 |
| 1 | 20-pin power socket | PinSocket_2x10_P2.54mm_Horizontal_DIB_V1 | J1 |
| 1 | VS_SCL | PinHeader_1x03_P2.00mm_Vertical | J2 |
| 1 | 28-pin module socket | PinHeader_2x14_P2.54mm_Horizontal_DIB_V1 | J3 |
| 2 | 691327310016 | 691327310016 | J4, J5 |
| 1 | HS_SDA | PinHeader_1x03_P2.00mm_Vertical | J6 |
| 1 | JMP_A0 | PinHeader_1x03_P2.00mm_Vertical | J7 |
| 1 | DE_IRQ | PinHeader_1x03_P2.00mm_Vertical | J8 |
| 1 | DIB_V2 | PinHeader_2x10_P2.54mm_Horizontal | J9 |
Show 55 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | OS0 | PinHeader_1x03_P2.00mm_Vertical | J10 |
| 1 | OS1 | PinHeader_1x03_P2.00mm_Vertical | J11 |
| 1 | OS2 | PinHeader_1x03_P2.00mm_Vertical | J12 |
| 1 | PAR | PinHeader_1x03_P2.00mm_Vertical | J13 |
| 1 | RANGE | PinHeader_1x03_P2.00mm_Vertical | J14 |
| 1 | REF | PinHeader_1x03_P2.00mm_Vertical | J15 |
| 1 | MDD01M-09 MDD01 Mean Well | MDS01 | J16 |
| 1 | FTDI | PinHeader_2x03_P2.54mm_Vertical | J17 |
| 1 | Conn_01x10 | PinHeader_1x10_P1.00mm_Vertical | J18 |
| 2 | PCA-6-LA-40-HL-3 | FPC_40 | LCD_IN1, LCD_OUT1 |
| 2 | Conn_02x20_Odd_Even | PinSocket_2x20_P2.54mm_Vertical | ULX3S_L1, ULX3S_R1 |
| 1 | 1727-3649-6 BZX384-B30.115 Nexperia | SOD323-W | ZD1 |
| 1 | LED | LED_0603_1608Metric | TOUCH1 |
| 1 | RB751V40T1G RB751V40T1G or NSR0240 ON Semiconductor | SOD323-R | D1 |
| 6 | 1727-3808-1 D_TVS Nexperia | D_SOD-523 | D2, D3, D4, D5, D6, D7 |
| 1 | DLG-0403-4R7 FerroCore | DE0403 | L1 |
| 2 | CL160808T-6R8K-N L Chilisin | C_0603_1608Metric | L2, L3 |
| 1 | CL160808T-6R8K-N 6.8uF Chilisin | R_0603_1608Metric | L4 |
| 1 | CL31A475KPHNNNE 4u7 Samsung | C_1206_3216Metric | C1 |
| 24 | CL21B104KBCNNNC 100n Samsung | C_0603_1608Metric | C2, C7, C9, C10, C11, C12, C13, C14 +16 |
| 2 | CL10A105KA8NNNC 1u Samsung | C_0805_2012Metric | C3, C8 |
| 2 | CL21B103KBANNNC 10n Samsung | C_0805_2012Metric | C4, C6 |
| 1 | CL10A225KP8NNNC 2u2 Samsung | C_0805_2012Metric | C5 |
| 2 | CL21B334KOCNNNC 330n Samsung | C_0603_1608Metric | C15, C16 |
| 3 | CL21A106KOQNNNE 10uF Samsung | C_0805_2012Metric | C26, C28, C29 |
| 1 | C0805C105K8RACTU 1u/X7R-grade KEMET | C_0805_2012Metric | C27 |
| 2 | CL10A225KP8NNNC 2.2u Samsung | C_0603_1608Metric | C30, C32 |
| 2 | CL10A475KQ8NNNC 4.7u Samsung | C_0603_1608Metric | C31, C36 |
| 1 | VJ0603Y102KXACW1BC 1nF Vishay | C_0603_1608Metric | C37 |
| 6 | CL10A106MQ8NNNC 10u Samsung | C_0603_1608Metric | C42, C43, C44, C45, C54, C55 |
| 1 | CL10A105KA8NNNC 1u Samsung | C_0603_1608Metric | C46 |
| 1 | CL10A475KQ8NNNC 4.7uF Samsung | C_0603_1608Metric | C51 |
| 2 | NI | C_0603_1608Metric | C60, C61 |
| 1 | 12101U371KAT2A 370pF AVX | C_0603_1608Metric | C62 |
| 2 | 0603B471K500CT 470p Walsin Technologies | C_0603_1608Metric | C63, C64 |
| 2 | VJ0603Y102KXACW1BC 1n Vishay | C_0603_1608Metric | C65, C66 |
| 4 | C0603C271J5GACTU 270pF KEMET | C_0603_1608Metric | C67, C68, C69, C70 |
| 2 | VJ0603Y223KXXCW1BC 22nF Vishay | C_0603_1608Metric | C71, C72 |
| 6 | 0805S8J0100T5E 10R Royal Ohm | R_0805_2012Metric | R1, R2, R46, R47, R48, R49 |
| 4 | 0805S8J0103T5E 10K Royal Ohm | R_0805_2012Metric | R3, R12, R16, R57 |
| 1 | 0805S8J0203T5E 20K Royal Ohm | R_0805_2012Metric | R4 |
| 1 | 4K7 | R_0805_2012Metric | R5 |
| 4 | 0805S8J0101T5E 100 Royal Ohm | R_0805_2012Metric | R6, R7, R8, R9 |
| 1 | 0805S8J0101T5E 100R Royal Ohm | R_0805_2012Metric | R11 |
| 3 | 0805S8J0103T5E 10K Royal Ohm | C_0805_2012Metric | R13, R14, R15 |
| 9 | 0805S8J0102T5E 1K Royal Ohm | R_0805_2012Metric | R17, R18, R19, R20, R21, R22, R23, R32 +1 |
| 1 | TC0650B499JT5 49R9 Royal Ohm | R_1206_3216Metric | R24 |
| 1 | NI | R_0805_2012Metric | R25 |
| 3 | 0805S8F499JT5E 49R9 Royal Ohm | R_0805_2012Metric | R26, R27, R50 |
| 4 | 1K2 | R_1206_3216Metric | R28, R29, R30, R31 |
| 4 | 1206S4J0301T5E 300R Royal Ohm | R_1206_3216Metric | R33, R34, R36, R37 |
| 4 | 0805S8J0122T5E 1K2 Royal Ohm | R_0805_2012Metric | R38, R39, R40, R41 |
| 4 | 0805S8F510KT5E 5R Royal Ohm | R_0805_2012Metric | R42, R43, R44, R45 |
| 4 | 1206S4J0102T5E 1K Royal Ohm | R_1206_3216Metric | R51, R52, R53, R54 |
| 2 | R0 | R_0201_0603Metric | R55, R56 |
LCD PMOD design files
The KiCad project lives in the goran-mahovlic/LVDS_RGB_experimental repository on GitHub; these links point at the commit this page was built from.
LCD PMOD: common questions
How big is the LCD PMOD PCB?
The LCD PMOD measures 175.3 × 95.3 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the LCD PMOD?
166 components, from 75 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the LCD PMOD design files?
From the goran-mahovlic/LVDS_RGB_experimental repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the LCD PMOD design in my own project?
The repository has no license, so all rights stay with goran-mahovlic. Use it as a reference, and ask the author before reusing the design.
