About the Open ambient sensor PCB
Open ambient sensor is an open source ESP32 PCB design by hubertciebiada, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 120 × 103.5 mm, with 52 components from 30 distinct parts.
Its main chip is the ESP32 row A (pins 1..15, antenna-side row), from the ESP32 family. Other key parts include the LM2596S-5.0/NOPB and TPS62933DRLR. By type, the board carries 23 capacitors, 10 diodes, 7 resistors, 6 connectors, 2 ICs and 2 inductors.
It belongs with the sensors and iot & wireless designs in this gallery.
From the project
OAS — Open Ambient Sensor: DIY multi-sensor indoor environmental monitor (CO2, PM, VOC/NOx, temperature/humidity, mmWave presence) on ESP32-C6 with ESPHome / Home Assistant integration
DIY multi-sensor environmental monitor for indoor spaces. Measures air quality and presence; mounts on a standard wall-recessed electrical box; runs ESPHome and integrates natively with Home Assistant.
v0.54 — manufactured, bench-validated and in use. Boards of this revision were fabricated and SMT-assembled at JLCPCB, brought up on the bench with a repeatable per-unit check, and run in a multi-unit deployment as the sensor input for Home Assistant HVAC automations. Working on the delivered hardware: the 24 V power chain, the Sensirion SEN66 (CO₂ / PM / VOC / NOx / T / RH, with Sensirion's…

Main components on the Open ambient sensor
Open ambient sensor bill of materials (BOM)
52 components, 30 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LM2596S-5.0/NOPB LM2596S-5.0 Texas Instruments | TO-263-5_LM2596 | U1 |
| 1 | TPS62933DRLR TPS62933 Texas Instruments | SOT-583-8 | U2 |
| 1 | AO3401A Alpha & Omega Semiconductor | SOT-23 | Q1 |
| 1 | Phoenix_MSTBA_2,5/3-G-5,08 (24V input) | PhoenixContact_MSTBA_2,5_3-G-5,08_1x03_P5.08mm_Horizontal | J1 |
| 1 | SM06B-GHS-TB(LF)(SN) JST SM06B-GHS-TB (SEN66 connector) JST Sales America | JST_GH_SM06B-GHS-TB_1x06-1MP_P1.25mm_Horizontal | J3 |
| 1 | 1x5 P2.54mm header (HLK-LD2410C) | PinHeader_1x05_P2.54mm_Vertical | J4 |
| 1 | ESP32 row A (pins 1..15, antenna-side row) | PinSocket_1x15_P2.54mm_Vertical | J5 |
| 1 | ESP32 row B (pins 16..30, USB-side row) | PinSocket_1x15_P2.54mm_Vertical | J6 |
| 1 | SM04B-SRSS-TB(LF)(SN) JST SM04B-SRSS-TB (Qwiic / Stemma QT) JST Sales America | JST_SH_SM04B-SRSS-TB_1x04-1MP_P1.00mm_Horizontal | J9 |
| 1 | 1812L075/33DR Littelfuse | Fuse_1812L_4532Metric | F1 |
| 1 | SMBJ24A Brightking | D_SMB | D1 |
| 1 | SS14 MDD (Microdiode Semiconductor) | D_SMA | D2 |
| 1 | BZT52C10S 10V Zener 200mW Nanjing Semtech Electronics | D_SOD-323 | D3 |
| 7 | SK6812SIDE-A SK6812-SIDE OPSCO Optoelectronics | SK6812-SIDE | D11, D12, D14, D15, D16, D17, D18 |
| 1 | CKCS5040-33uH/M 33uH CENKER | L_Cenker_CKCS5040 | L1 |
| 1 | CKCS5040-2.2uH/M 2.2uH CENKER | L_Cenker_CKCS5040 | L2 |
| 2 | 100uF/50V | CP_Radial_D8.0mm_P3.50mm | C1, C3 |
| 1 | GRM21BR72A103KA01L 10nF Y2 Murata Electronics | C_0805_2012Metric | C2 |
| 1 | 220uF/10V | CP_Radial_D6.3mm_P2.50mm | C4 |
| 2 | CL21A106KAYNNNE 10uF Samsung Electro-Mechanics | C_0805_2012Metric | C5, C9 |
Show 10 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | CL21A226MAQNNNE 22uF Samsung Electro-Mechanics | C_0805_2012Metric | C6 |
| 8 | CC0603KRX7R9BB104 100nF Yageo | C_0603_1608Metric | C7, C10, C11, C13, C14, C15, C16, C17 |
| 1 | CL10B473KB8NNNC 47nF Samsung Electro-Mechanics | C_0603_1608Metric | C8 |
| 7 | CL05B104KO5NNNC 100nF Samsung Electro-Mechanics | C_0402_1005Metric | C20, C21, C23, C24, C25, C26, C27 |
| 1 | 0603WAF1003T5E 100k 1% UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R1 |
| 1 | 0603WAF1003T5E 100k UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R2 |
| 1 | 0603WAF3092T5E 30.9k UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R3 |
| 1 | 0603WAF1001T5E 1k UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R4 |
| 2 | 0603WAF4701T5E 4.7k UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R5, R6 |
| 1 | 0603WAF1002T5E 10k UNI-ROYAL (Uniroyal Elec) | R_0603_1608Metric | R7 |
Open ambient sensor design files
The KiCad project lives in the hubertciebiada/open-ambient-sensor repository on GitHub; these links point at the commit this page was built from.
Open ambient sensor: common questions
What microcontroller does the Open ambient sensor use?
The Open ambient sensor is built around the ESP32 row A (pins 1..15, antenna-side row), from the ESP32 family.
How big is the Open ambient sensor PCB?
The Open ambient sensor measures 120 × 103.5 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Open ambient sensor?
52 components, from 30 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Open ambient sensor design files?
From the hubertciebiada/open-ambient-sensor repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Open ambient sensor design in my own project?
Yes, under the terms of its GPL-3.0 license, which hubertciebiada chose for the repository.
Can I test firmware for the Open ambient sensor without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
