ControllerBoard PCB layout, top view — open source board by inria-emeraude

About the ControllerBoard PCB

ControllerBoard is an open source PCB design by inria-emeraude, published on GitHub. It is a 2-layer board measuring 129 × 83.8 mm, with 37 components from 10 distinct parts.

Other key parts include the MCP3008. By type, the board carries 8 switches, 8 resistors, 2 connectors, 1 IC and 1 capacitor.

It belongs with the audio and dev boards & breakouts designs in this gallery.

From the project

A faust-to-fpga compiler toolchain

This repository contains the open-source hardware designs for the PCB boards developed as part of the Syfala project. These boards provide the physical interfaces between an FPGA and multichannel loudspeaker or microphone arrays, and a hardware control surface for DSP parameter control.

All designs are released as open-source KiCad projects, including schematics, PCB layouts, and Gerber files.

ControllerBoard, from the project README — From the project README

Main components on the ControllerBoard

ControllerBoard bill of materials (BOM)

37 components, 10 distinct parts.

Qty	Part	Footprint	Refs
1	MCP3008	DIP-16_W7.62mm_Socket_LongPads	U1
1	Conn_02x06_Odd_Even	PinHeader_2x06_P2.54mm_Horizontal	J1
1	Conn_02x06_Odd_Even	PinHeader_2x06_P2.54mm_Vertical	J2
8	10k	Potentiometer_Omeg_PC16BU_Vertical	RV1, RV2, RV3, RV4, RV5, RV6, RV7, RV8
8	10k	Potentiometer_Bourns_PTA6043_Single_Slide	RV11, RV12, RV13, RV14, RV15, RV16, RV17, RV18
8	SW_Push	SW_PUSH_6mm	SW1, SW2, SW3, SW4, SW5, SW6, SW7, SW8
1	G***	grame	svg2mod
1	10p	C_Disc_D5.0mm_W2.5mm_P2.50mm	C1
4	10k	R_Axial_DIN0207_L6.3mm_D2.5mm_P10.16mm_Horizontal	R1, R3, R5, R7
4	10k	R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal	R2, R4, R6, R8

ControllerBoard design files

The KiCad project lives in the inria-emeraude/syfala repository on GitHub; these links point at the commit this page was built from.

LayoutPCB/ControllerBoard/controllerBoard.kicad_pcb

ControllerBoard: common questions

How big is the ControllerBoard PCB?

The ControllerBoard measures 129 × 83.8 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the ControllerBoard?

37 components, from 10 distinct parts. The full bill of materials is listed on this page.

Where can I download the ControllerBoard design files?

From the inria-emeraude/syfala repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the ControllerBoard design in my own project?

The repository has no license, so all rights stay with inria-emeraude. Use it as a reference, and ask the author before reusing the design.
