Project ma rust

About the Project ma rust PCB

Project ma rust is an open source RP2040/RP2350 PCB design by istudormihai, published on GitHub. It is a board, with 12 components from 9 distinct parts.

Its main chip is the SC0918, from the RP2040/RP2350 family. Other key parts include the L298N. By type, the board carries 5 modules, 3 resistors, 1 IC and 1 battery holder.

It belongs with the robotics & motion and sensors designs in this gallery.

From the project

Author: Istudor Victor Mihai \ GitHub Project Link: https://github.com/istudormihai/project-ma-rust)

Author: Istudor Victor Mihai \ GitHub Project Link: https://github.com/istudormihai/project-ma-rust)

This robot will be capable of following a trajectory given by a black line on a white background, with the help of two infrared sensors placed in the front. The robot will be powered by 4 AA batteries that will give current to 4 DC motors connected to a L298N motor driver.

Main components on the Project ma rust

L298NSC0918

Project ma rust bill of materials (BOM)

12 components, 9 distinct parts.

QtyPartRefs
1
L298N
U1
1
SC0918
A1
4
Motor_DC
M1, M2, M3, M4
1
Battery
BT1
1
—
LM358
1
10K
RV1
1
100
R1
1
10K
R2
1
330
R3

Project ma rust design files

The KiCad project lives in the istudormihai/project-ma-rust repository on GitHub; these links point at the commit this page was built from.

Project ma rust: common questions

What microcontroller does the Project ma rust use?

The Project ma rust is built around the SC0918, from the RP2040/RP2350 family.

How many components are on the Project ma rust?

12 components, from 9 distinct parts. The full bill of materials is listed on this page.

Where can I download the Project ma rust design files?

From the istudormihai/project-ma-rust repository on GitHub, which has the schematic; the links under Design files point to each one.

Can I use the Project ma rust design in my own project?

The repository has no license, so all rights stay with istudormihai. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Project ma rust without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
