USB conn
About the USB conn PCB
USB conn is an open source PCB design by Jana-Marie, published on GitHub. It is a 2-layer board measuring 21.8 × 20.5 mm, with 11 components from 5 distinct parts.
It belongs with the power & battery designs in this gallery.
From the project
USB-PD soldering station for JBC C245 handles.
USB conn bill of materials (BOM)
11 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | USB_C_RECEPTACLE_USB2.0 Conn_01x10 | PinHeader_1x10_P2.00mm_Vertical | J1 |
| 1 | OLED_64X32 Conn_01x01 | pad_1.5_3 | J2 |
| 1 | C245 Conn_01x01 | pad_1.5_3 | J3 |
| 2 | Conn_01x01 | pad_0.75_3 | J4, J5 |
| 6 | Conn_01x01 | pad_1_2 | J6, J7, J8, J9, J10, J11 |
USB conn design files
The KiCad project lives in the Jana-Marie/Otter-Iron-PRO repository on GitHub; these links point at the commit this page was built from.
USB conn: common questions
How big is the USB conn PCB?
The USB conn measures 21.8 × 20.5 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the USB conn?
11 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the USB conn design files?
From the Jana-Marie/Otter-Iron-PRO repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the USB conn design in my own project?
The repository has no license, so all rights stay with Jana-Marie. Use it as a reference, and ask the author before reusing the design.
