About the TravelModule-2023 PCB

TravelModule-2023 is an open source NXP PCB design by LesKaribous, published on GitHub under the MIT license. It is a 2-layer board measuring 27 × 54 mm, with 7 components from 6 distinct parts.

Its main chip is the Teensy3.2, from the NXP family. By type, the board carries 2 connectors, 1 IC, 1 diode and 1 resistor.

It belongs with the robotics & motion designs in this gallery.

From the project

Hardware du robot des Karibous pour la Coupe de Robotique (Eurobot) 2022

Les Karibous, c'est une équipe de robotique fondée en 2011 avec la ferme intention de montrer que la robotique peut être simple et fun à réaliser. Depuis cette époque, elle participe chaque année à La Coupe de France de Robotique organisée par l'association Planète Science ainsi qu'à la MakerFight !

Chaque semaine, suivez l'évolution de nos robots en live twitch sur Barbatronic Live ! - Plus d'informations sur la Coupe de France de robotique : coupederobotique.fr - Plus d'informations sur notre équipe : Les Karibous

TravelModule-2023, from the project README
From the project README

Main components on the TravelModule-2023

Teensy3.2

TravelModule-2023 bill of materials (BOM)

7 components, 6 distinct parts.

QtyPartRefs
1
Teensy3.2
U1
1
PMW3901
J1
1
BNO055
J2
2
MountingHole
H1, H2
1
LED_Small
D1
1
R_Small
R1

TravelModule-2023 design files

The KiCad project lives in the LesKaribous/Karibous-2023-Hardware repository on GitHub; these links point at the commit this page was built from.

TravelModule-2023: common questions

What microcontroller does the TravelModule-2023 use?

The TravelModule-2023 is built around the Teensy3.2, from the NXP family.

How big is the TravelModule-2023 PCB?

The TravelModule-2023 measures 27 × 54 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the TravelModule-2023?

7 components, from 6 distinct parts. The full bill of materials is listed on this page.

Where can I download the TravelModule-2023 design files?

From the LesKaribous/Karibous-2023-Hardware repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the TravelModule-2023 design in my own project?

Yes, under the terms of its MIT license, which LesKaribous chose for the repository.

Can I test firmware for the TravelModule-2023 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug NXP firmware against it before you order a PCB.
