Processing PCB layout, top view — open source NXP board by mamaheux

About the Processing PCB

Processing is an open source NXP PCB design by mamaheux, published on GitHub under the MIT license. It is a 2-layer board measuring 100 × 100 mm, with 194 components from 60 distinct parts.

Its main chip is the Teensy_4.0, from the NXP family. Other key parts include the TL074, TL072, MCP6541, SN74AUC1G74 and CS4270. By type, the board carries 72 resistors, 57 capacitors, 31 test points, 10 ICs, 10 diodes and 8 connectors.

It belongs with the audio designs in this gallery.

Processing, from the project README
From the project README

Main components on the Processing

TL074TL072Teensy_4.0MCP6541SN74AUC1G74CS4270

Processing bill of materials (BOM)

194 components, 60 distinct parts.

QtyPartRefs
4
TL074
U1, U2, U4, U5
2
TL072
U3, U10
1
Teensy_4.0
U6
1
MCP6541
U7
1
SN74AUC1G74
U8
1
CS4270
U9
1
TD9944
Q1
1
MMUN2111LT1
Q3
1
MMBT2222A
Q4
2
Conn_01x06_Male
J1, J2
1
power_amp
J3
1
control board
J4
1
AudioJack2_X4
J5
1
AudioJack2_XLR_SW
J6
1
Conn_01x03_Male
J7
1
Conn_01x02_Male
J8
2
R_POT
RV1, RV2
1
10k
RV_SW1
31
TP
TP1, TP2, TP3, TP4, TP5, TP6, TP7, TP8 +23
8
12V
D1, D2, D3, D4, D5, D6, D7, D8
Show 40 more
QtyPartRefs
2
6.2V
D9, D10
4
1000µF/25V
C1, C2, C3, C4
21
2.2µF/25V/UL ESR
C5, C6, C7, C8, C9, C10, C11, C12 +13
1
100pF/100V
C19
2
220pF/100V
C20, C24
9
10µF/50V
C21, C26, C28, C29, C33, C36, C41, C42 +1
1
0.1µF/100V
C22
1
0.22µF/100V
C23
1
1nF/100V
C25
3
4.7nF/100V
C27, C31, C32
1
0.047µF/100V
C38
2
3.3µF/25V
C39, C40
1
3600pF/50V
C43
2
220pF/50V
C44, C45
4
0.1µF/25V
C47, C48, C53, C54
1
47µF/10V
C49
1
10µF/10V
C50
2
1µF/6.3V
C51, C52
9
0
R1, R4, R5, R8, R16, R18, R21, R39 +1
4
inf
R2, R6, R11, R19
17
10k
R3, R12, R15, R30, R31, R38, R40, R41 +9
1
47.5k
R7
2
12.1k
R9, R13
1
1M
R10
1
221
R14
1
2.21k
R17
1
56.2k
R20
1
23.7k
R22
8
5.11k
R23, R24, R27, R28, R35, R46, R47, R50
5
20k
R25, R29, R44, R45, R51
2
10.2k
R26, R34
2
1k
R32, R33
2
100k
R36, R37
1
4.75k
R52
7
2k
R54, R55, R59, R60, R66, R68, R69
2
470
R58, R61
1
3.09k
R62
1
15.4k
R64
1
560
R67
2
inf or 47k
R71, R72

Processing design files

The KiCad project lives in the mamaheux/bass-amplifier repository on GitHub; these links point at the commit this page was built from.

Processing: common questions

What microcontroller does the Processing use?

The Processing is built around the Teensy_4.0, from the NXP family.

How big is the Processing PCB?

The Processing measures 100 × 100 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Processing?

194 components, from 60 distinct parts. The full bill of materials is listed on this page.

Where can I download the Processing design files?

From the mamaheux/bass-amplifier repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Processing design in my own project?

Yes, under the terms of its MIT license, which mamaheux chose for the repository.

Can I test firmware for the Processing without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug NXP firmware against it before you order a PCB.
