Haut de Forme
martinroger·ipodesp32·pcbs/legacy boards/hautDeForme/hautDeForme.kicad_pcb
About the Haut de Forme PCB
Haut de Forme is an open source PCB design by martinroger, published on GitHub under the MIT license. It is a 2-layer board measuring 29.8 × 68.3 mm, with 27 components from 17 distinct parts.
Other key parts include the AZ1117CH-3.3TRG1 and CP2102-GM. By type, the board carries 12 resistors, 6 diodes, 6 capacitors, 2 ICs and 1 connector.
It belongs with the iot & wireless designs in this gallery.
From the project
An iPod emulator for 2006-2013 BMW Mini Coopers that need Bluetooth

Main components on the Haut de Forme
Haut de Forme bill of materials (BOM)
27 components, 17 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | AZ1117CH-3.3TRG1 | SOT-223-3_TabPin2 | U2 |
| 1 | CP2102-GM | QFN-28-1EP_5x5mm_P0.5mm_EP3.35x3.35mm | U4 |
| 1 | USB4105-GF-A | GCT_USB4105-GF-A | J6 |
| 1 | LTST-C190AKT 2.1V O 10mA | LED_0603_1608Metric | D5 |
| 1 | LTST-C190EKT 2V R 10mA | LED_0603_1608Metric | D6 |
| 1 | SP0503BAHTG | SOT-143 | D8 |
| 2 | LTST-C190GKT 2.1V G 10mA | LED_0603_1608Metric | D9, D11 |
| 1 | 1N5819HW-7-F | D_SOD-123 | D14 |
| 3 | CC0805MKX5R6BB226 22uF 10V | C_0805_2012Metric | C6, C7, C16 |
| 2 | CL10A106KP8NNNC 10uF 10V | C_0603_1608Metric | C13, C15 |
| 1 | CL10B104KB8NNNC 0.1uF 50V | C_0603_1608Metric | C14 |
| 4 | RC0603FR-071KL 1K 1% | R_0603_1608Metric | R5, R6, R34, R35 |
| 1 | RMCF0603FT22K1 22.1K 1% | R_0603_1608Metric | R23 |
| 1 | ERJ-3EKF4752V 47.5K 1% | R_0603_1608Metric | R24 |
| 1 | RMCF0603FT2K00 2K 1% | R_0603_1608Metric | R25 |
| 3 | RMCF0603ZT0R00 0R | R_0603_1608Metric | R26, R27, R29 |
| 2 | RC0603FR-075K1L 5.1K 1% | R_0603_1608Metric | R28, R30 |
Haut de Forme design files
The KiCad project lives in the martinroger/ipodesp32 repository on GitHub; these links point at the commit this page was built from.
Haut de Forme: common questions
How big is the Haut de Forme PCB?
The Haut de Forme measures 29.8 × 68.3 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Haut de Forme?
27 components, from 17 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Haut de Forme design files?
From the martinroger/ipodesp32 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Haut de Forme design in my own project?
Yes, under the terms of its MIT license, which martinroger chose for the repository.
