A1S Mini Board
martinroger·ipodesp32·pcbs/legacy boards/a1s-mini/a1s-mini.kicad_pcb
About the A1S Mini Board
A1S Mini Board is an open source PCB design by martinroger, published on GitHub under the MIT license. It is a 2-layer board measuring 58.8 × 55.8 mm, with 70 components from 24 distinct parts.
Other key parts include the AZ1117CH-3.3TRG1, CP2102N-A02-GQFN28R and CP2102-GM. By type, the board carries 33 resistors, 16 capacitors, 10 diodes, 3 ICs, 3 transistors and 3 connectors.
It belongs with the iot & wireless designs in this gallery.
From the project
An iPod emulator for 2006-2013 BMW Mini Coopers that need Bluetooth

Main components on the A1S Mini Board
A1S Mini Board bill of materials (BOM)
70 components, 24 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | AZ1117CH-3.3TRG1 | SOT-223-3_TabPin2 | U2 |
| 1 | CP2102N-A02-GQFN28R CP2102N | QFN-28-1EP_5x5mm_P0.5mm_EP3.35x3.35mm | U3 |
| 1 | CP2102-GM | QFN-28-1EP_5x5mm_P0.5mm_EP3.35x3.35mm | U4 |
| 1 | BC818-40LT1G BC818 | SOT-23 | Q3 |
| 2 | MBT3904DW1T1G MBT3904DW1 | SOT-363_SC-70-6 | Q4, Q6 |
| 1 | SJ-3524-SMT-TR-PI | Jack_3.5mm_CUI_SJ-3524-SMT_Horizontal | J2 |
| 2 | USB4105-GF-A | GCT_USB4105-GF-A | J5, J6 |
| 2 | TL3305BF260QG | TL3305BF260QG | S1, S2 |
| 4 | LTST-C190GKT 2.1V G 10mA | LED_0603_1608Metric | D1, D2, D9, D11 |
| 1 | LTST-C190AKT 2.1V O 10mA | LED_0603_1608Metric | D5 |
| 1 | LTST-C190EKT 2V R 10mA | LED_0603_1608Metric | D6 |
| 2 | SP0503BAHTG | SOT-143 | D7, D8 |
| 2 | 1N5819HW-7-F | SOD3716X145N | D10, D14 |
| 8 | CL10B104KB8NNNC 0.1uF 50V Kemet | C_0603_1608Metric | C1, C3, C4, C5, C8, C9, C11, C14 |
| 4 | CC0805MKX5R6BB226 22uF 10V Yageo | C_0805_2012Metric | C2, C6, C7, C16 |
| 4 | CL10A106KP8NNNC 10uF 10V | C_0603_1608Metric | C10, C12, C13, C15 |
| 6 | RC0603FR-071KL 1K 1% | R_0603_1608Metric | R1, R2, R5, R6, R34, R35 |
| 6 | CR0603-FX-1002ELF 10K 1% | R_0603_1608Metric | R7, R12, R13, R14, R32, R33 |
| 2 | RC0603FR-0722RL 22R 1% | R_0603_1608Metric | R8, R9 |
| 9 | RMCF0603ZT0R00 0R | R_0603_1608Metric | R10, R11, R18, R19, R21, R26, R27, R29 +1 |
Show 4 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | RMCF0603FT22K1 22.1K 1% | R_0603_1608Metric | R15, R23 |
| 2 | ERJ-3EKF4752V 47.5K 1% | R_0603_1608Metric | R16, R24 |
| 2 | RMCF0603FT2K00 2K 1% | R_0603_1608Metric | R17, R25 |
| 4 | RC0603FR-075K1L 5.1K 1% | R_0603_1608Metric | R20, R22, R28, R30 |
A1S Mini Board design files
The KiCad project lives in the martinroger/ipodesp32 repository on GitHub; these links point at the commit this page was built from.
A1S Mini Board: common questions
How big is the A1S Mini Board?
The A1S Mini Board measures 58.8 × 55.8 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the A1S Mini Board?
70 components, from 24 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the A1S Mini Board design files?
From the martinroger/ipodesp32 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the A1S Mini Board design in my own project?
Yes, under the terms of its MIT license, which martinroger chose for the repository.
