Simple carrier board (CP2104)
martinroger·ipodesp32·pcbs/sandwichCircuit/sandwichCircuit.kicad_pcb
About the Simple carrier board (CP2104)
Simple carrier board (CP2104) is an open source ESP32 PCB design by martinroger, published on GitHub under the MIT license. It is a 2-layer board measuring 76 × 56 mm, with 9 components from 9 distinct parts.
Its main chip is the ESP32-DevKitC header, from the ESP32 family. Other key parts include the 3678 and CP2104 USB A board. By type, the board carries 3 ICs, 3 jumpers, 1 connector, 1 capacitor and 1 resistor.
It belongs with the iot & wireless, usb & debug tools and dev boards & breakouts designs in this gallery.
From the project
An iPod emulator for 2006-2013 BMW Mini Coopers that need Bluetooth

Main components on the Simple carrier board (CP2104)
Simple carrier board (CP2104) bill of materials (BOM)
9 components, 9 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 3678 Prolific | Adafruit 3678 | IC1 |
| 1 | ESP32-DevKitC header | ESP32-DevKitC | U1 |
| 1 | CP2104 USB A board | CP2104_USB_Board | U2 |
| 1 | Audio Out | PinHeader_1x03_P2.54mm_Vertical | J5 |
| 1 | SolderJumper_3_Bridged12 | SolderJumper-3_P1.3mm_Bridged12_RoundedPad1.0x1.5mm | JP1 |
| 1 | SolderJumper_2_Bridged | SolderJumper-2_P1.3mm_Bridged_RoundedPad1.0x1.5mm | JP2 |
| 1 | SolderJumper_2_Open | SolderJumper-2_P1.3mm_Open_RoundedPad1.0x1.5mm | JP3 |
| 1 | CL10A475KP8NNNC 10uF 10V Samsung Electro-Mechanics | C_Radial_D5.0mm_H7.0mm_P2.00mm | C1 |
| 1 | 50R | R_Axial_DIN0207_L6.3mm_D2.5mm_P10.16mm_Horizontal | R1 |
Simple carrier board (CP2104) design files
The KiCad project lives in the martinroger/ipodesp32 repository on GitHub; these links point at the commit this page was built from.
Simple carrier board (CP2104): common questions
What microcontroller does the Simple carrier board (CP2104) use?
The Simple carrier board (CP2104) is built around the ESP32-DevKitC header, from the ESP32 family.
How big is the Simple carrier board (CP2104)?
The Simple carrier board (CP2104) measures 76 × 56 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Simple carrier board (CP2104)?
9 components, from 9 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Simple carrier board (CP2104) design files?
From the martinroger/ipodesp32 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Simple carrier board (CP2104) design in my own project?
Yes, under the terms of its MIT license, which martinroger chose for the repository.
Can I test firmware for the Simple carrier board (CP2104) without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
