About the ISM02 PCB
ISM02 is an open source PCB design by mlab-modules, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 50.3 × 30 mm, with 51 components from 31 distinct parts.
Other key parts include the SX1262, MIC5504-3.3YM5 and PE4259. By type, the board carries 23 capacitors, 14 connectors, 7 inductors, 3 ICs, 2 resistors and 1 crystal.
It belongs with the rf & radio and iot & wireless designs in this gallery.
From the project
ISM RF module with LoRa network capability
ISM02A is a telemetry module based on the Semtech SX1262 RF transceiver. This module is widely used in LoRa and other sub-GHz wireless communication applications. It incorporates an RF switch (PE4259) to multiplex RX and TX on a single antenna, making it a compact solution for IoT and telemetry use cases.
The module is typically used as a LoRa device and offers flexible wireless communication for various low-power, long-range applications.
Main components on the ISM02
ISM02 bill of materials (BOM)
51 components, 31 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | SX1262 | QFN-24-1EP_4x4mm_P0.5mm_EP2.6x2.6mm_ThermalVias | U1 |
| 1 | MIC5504-3.3YM5 | SOT-23-5 | U2 |
| 1 | PE4259 | SOT-363_SC-70-6 | U3 |
| 1 | NX2016SA-32M-EXS00A-CS06465 32MHz | Crystal_SMD_NX2016SA | Y1 |
| 1 | JUMP_3X2 | Straight_2x03 | J1 |
| 12 | HEADER_2x01_PARALLEL | Straight_2x01 | J2, J3, J4, J5, J6, J7, J8, J9 +4 |
| 1 | MCX | MCX | J12 |
| 1 | BZV55C-5,6V | Diode-MiniMELF_Standard | D1 |
| 1 | 15UH 15uH | SMD-0805 | L1 |
| 1 | LQW15AN15NH00D 15nH | L_0402_1005Metric | L2 |
| 1 | 0R | L_0402_1005Metric | L3 |
| 1 | LQW15AN47NJ00D 47nH | L_0402_1005Metric | L4 |
| 1 | LQW15AN2N5C00D 2n5 | L_0402_1005Metric | L5 |
| 1 | LQW15AN4N7C00D 4n7 | L_0402_1005Metric | L6 |
| 1 | LQW15AN9N1H00D 9n1 | L_0402_1005Metric | L7 |
| 4 | - | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C1, C3, C11, C12 |
| 2 | 100NF 100nF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C2, C6 |
| 1 | 470NF 470nF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C4 |
| 1 | 1UF 1uF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C5 |
| 1 | 47NF 47nF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C7 |
Show 11 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 1P8 1p8 | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C8 |
| 1 | 47PF 47pF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C9 |
| 1 | 2P4 2p4 | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C10 |
| 3 | 3p3 | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C13, C19, C22 |
| 1 | 5P6 5p6 | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C14 |
| 2 | 39pF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C15, C17 |
| 1 | 2P2 2p2 | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C16 |
| 1 | 1NF 1nF | C_0603_1608Metric_Pad1.05x0.95mm_HandSolder | C18 |
| 3 | 10uF | SMD-0805 | C21, C24, C25 |
| 1 | 10K 10k | SMD-0603 | R1 |
| 1 | 100R | SMD-0603 | R2 |
ISM02 design files
The KiCad project lives in the mlab-modules/ISM02 repository on GitHub; these links point at the commit this page was built from.
ISM02: common questions
How big is the ISM02 PCB?
The ISM02 measures 50.3 × 30 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the ISM02?
51 components, from 31 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the ISM02 design files?
From the mlab-modules/ISM02 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the ISM02 design in my own project?
Yes, under the terms of its GPL-3.0 license, which mlab-modules chose for the repository.
