Cs2

na103·7-drive·kicad/cs2/cs2.kicad_pcb

Cs2 PCB layout, top view — open source board by na103
Simulate this board

About the Cs2 PCB

Cs2 is an open source PCB design by na103, published on GitHub under the CC-BY-NC-4.0 license. It is a 2-layer board measuring 48 × 25 mm, with 6 components from 6 distinct parts.

Other key parts include the 74LS02 and 74LS27. By type, the board carries 2 ICs, 2 capacitors, 1 connector and 1 resistor.

It belongs with the displays & leds and retro computing designs in this gallery.

From the project

Amiga 7 segment floppy drive display monitor

here you can find the mouser project with all the components, Db23 connectors excluded. https://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=75b1d9bf4b

you can see here the steps to follow to build the board. gerber of the three board is inside kicad projects switch in upper position show DF0 activity, down DF1 is avaible an optional 3d printed case. thanks to Roberto Camparini for stl file

Cs2, from the project README
From the project README

Main components on the Cs2

74LS0274LS27

Cs2 bill of materials (BOM)

6 components, 6 distinct parts.

QtyPartRefs
1
74LS02
U1
1
74LS27
U2
1
Conn_01x18_Male
J4
1
4.7nF
C1
1
100nF
C2
1
3.9K
R1

Cs2 design files

The KiCad project lives in the na103/7-drive repository on GitHub; these links point at the commit this page was built from.

Cs2: common questions

How big is the Cs2 PCB?

The Cs2 measures 48 × 25 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Cs2?

6 components, from 6 distinct parts. The full bill of materials is listed on this page.

Where can I download the Cs2 design files?

From the na103/7-drive repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Cs2 design in my own project?

It is published under CC-BY-NC-4.0, which limits how it may be reused; read the license before building on it.
