AllSerial eBus PCB layout, top view — open source board by Phunkafizer

About the AllSerial eBus PCB

AllSerial eBus is an open source PCB design by Phunkafizer, published on GitHub under the MIT license. It is a 2-layer board measuring 67.4 × 44.8 mm, with 39 components from 22 distinct parts.

Other key parts include the LM293. By type, the board carries 16 resistors, 10 diodes, 6 transistors, 2 connectors, 2 inductors and 1 IC.

It belongs with the usb & debug tools and iot & wireless designs in this gallery.

From the project

An universal sophisticated USB-serial converter

SEE PROJECTHOMEPAGE UNDER https://www.seegel-systeme.de/2025/07/10/allserial

Over the course of time I had to work with many different devices which had to be connected via a kind of serial interface. There are lots of different cheap USB-serial adapters available, but no adapter was including all features I needed in a single device. Every USB-serial adapter has in common the USB Controller. So I came up with the idea having a masterboard providing all the common features like USB interface, isolation and diagnostic elements. The most used interfaces (RS232, RS485, TTL UART, TTY current…

AllSerial eBus, from the project README
From the project README

Main components on the AllSerial eBus

LM293

AllSerial eBus bill of materials (BOM)

39 components, 22 distinct parts.
