About the Barramento V04 PCB

Barramento V04 is an open source PCB design by Pinheirogustavo, published on GitHub. It is a 2-layer board measuring 90 × 100 mm, with 44 components from 24 distinct parts.

Other key parts include the 74HC4051 and CD4066BE. By type, the board carries 15 connectors, 11 ICs, 10 capacitors, 4 inductors and 4 resistors.

From the project

- Os projetos desenvolvidos na versão Kicad 7.0 não são compatíveis com versões mais recentes.

- Sempre que for alterar um projeto abra o "arquivopro" específico, não o arquivo geral "KiCadProjects.kicadpro".

- Ao realizar alguma modificação de projeto elétrico (não somente design), Faça a alteração no arquivo esquemático "arquivosch" e depois altere o arquivo de design "arquivopcb" por meio da ferramenta de "atualize a PCI com as alterações feitas no esquema - F8" (símbolo no painel superior). Modificações realizadas no sentido contrário não são atualizadas no esquema e assim sua placa…

Barramento V04, from the project README — From the project README

Main components on the Barramento V04

74HC4051 CD4066BE

Barramento V04 bill of materials (BOM)

44 components, 24 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
10	74HC4051	N16	U1A1, U1B1, U2A2, U2B2, U3A3, U3B3, U4A4, U4B4 +2
1	CD4066BE BluePill_STM32F103C	BluePill_STM32F103C	U2
1	CONN_02X09_TOP_BOTTOM alimentacao analogica	PinHeader_1x08_P2.54mm_Vertical	J1
1	sinais analogicos	PinHeader_1x27_P2.54mm_Vertical	J2
1	comunicacao / sinais digitais	PinHeader_1x35_P2.54mm_Vertical	J3
1	Conn_01x03	PinHeader_1x03_P2.54mm_Vertical	J4
3	Conn_01x02	PinHeader_1x02_P2.54mm_Vertical	J5, J6, J7
1	+9Vmux	PinHeader_1x02_P2.54mm_Vertical	J8
1	+5Vmux	PinHeader_1x02_P2.54mm_Vertical	J9
1	+3.3Vmux	PinHeader_1x02_P2.54mm_Vertical	J10
1	-9Vmux	PinHeader_1x02_P2.54mm_Vertical	J11
1	-5Vmux	PinHeader_1x02_P2.54mm_Vertical	J12
1	GNDmux	PinHeader_1x02_P2.54mm_Vertical	J13
2	conectorEletrodos	PinHeader_2x24_P2.54mm_Vertical	J14, J15
1	LED Yelow	LED_D5.0mm	L+3.3v1
1	LED Green	LED_D5.0mm	L+5v1
1	LED Blue	LED_D5.0mm	L+9v1
1	LED Red	LED_D5.0mm	L-9v1
2	47u	CP_Radial_D5.0mm_P2.50mm	C1-5A1, C2-5B1
8	100n	C_Disc_D3.0mm_W1.6mm_P2.50mm	C1-A1, C1-A2, C1-A3, C1-A4, C2-B1, C2-B2, C2-B3, C2-B4

Show 4 more

Qty	Part	Footprint	Refs
1	220 1.5k	R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal	R1
1	100K 1.5k	R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal	R2
1	100K 470	R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal	R3
1	100K 510	R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal	R4
