Line follower PCB layout, top view — open source AVR/Arduino board by rmingon

About the Line follower PCB

Line follower is an open source AVR/Arduino PCB design by rmingon, published on GitHub. It is a 2-layer board measuring 93.5 × 97.5 mm, with 84 components from 24 distinct parts.

Its main chip is the ATmega2560-16A, from the AVR/Arduino family. Other key parts include the QRE1113GR, MX1508 and LM317_SOT-223. By type, the board carries 33 resistors, 21 capacitors, 13 ICs, 8 diodes, 5 connectors and 2 transistors.

It belongs with the robotics & motion and sensors designs in this gallery.

From the project

Line follower robot with internal fan for pin to the ground and 10 reflectances sensors head

This project is a Line Follower Robot using an ATmega2560 microcontroller. It features motor control, a reflective sensor array for line tracking, a fan controller, and voltage regulation.

- MCU: ATmega2560-16A - 10x QRE1113GR reflective IR sensors - 2x MX1508 motor drivers (H-bridge) - MOSFET-based fan control (2N7002) - Power via battery with 5V regulation (AMS1117) - 6x status LEDs - Standard AVR ISP programming header - Custom-designed PCB

Line follower, from the project README
From the project README

Main components on the Line follower

QRE1113GRATmega2560-16AMX1508LM317_SOT-223

Line follower bill of materials (BOM)

84 components, 24 distinct parts.
