About the TeenG5 PCB

TeenG5 is an open source NXP PCB design by septentrio-gnss, published on GitHub. It is a 4-layer board measuring 62.8 × 27 mm, with 39 components from 27 distinct parts.

Its main chip is the Untitled_1, from the NXP family. Other key parts include the MOSAIC-G5-P3, ECMF02-2AMX6, XC8111AA01MR-G, TPS7A9401DSCR and MPM3814C. By type, the board carries 12 capacitors, 12 resistors, 7 ICs, 6 connectors and 2 diodes.

It belongs with the dev boards & breakouts and rf & radio designs in this gallery.

From the project

TeenG5: Is an open source HW for mosaic G5 GNSS modules of Septentrio. It is a carrier board for Teensy computers.

What is TeenG5 What is the Teensy 4.1? What is a Carrier Board for Teensy 4.1? Produce Yourself? Do I Need to Source Special Components for Producing This Board? What is a mosaic-G5 Module? Other mosaic-G5 Versions Who is Septentrio? Deliverables Is the Project Open-Source? Disclaimer Documentation Sections

The board can also operate as a standalone device when powered through its USB connector.

TeenG5, from the project README
From the project README

Main components on the TeenG5

MOSAIC-G5-P3ECMF02-2AMX6XC8111AA01MR-GTPS7A9401DSCRMPM3814C

TeenG5 bill of materials (BOM)

39 components, 27 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
MOSAIC-G5-P3
mosaic-G5
U1
1
ECMF02-2AMX6
U2
2
XC8111AA01MR-G
U3, U7
1
~
U4
1
TPS7A9401DSCR
U5
1
MPM3814C
~
U8
2
u.FL
J2, J3
1
CONN_01X05_PIN
Conn_01x05_Pin
J4
1
USB4105-GF-A
~
J5
2
MMCX
J6, J7
1
LED
D1
1
ESDA7P120_1U1M
D2
2
10UF
10uF
C1, C2
1
4.7UF
4.7uF
C3
1
22UF
22uF
C4
1
100NF
100nF
C5
3
1UF
1uF
C8, C9, C10
4
22UF
22uF
C11, C13, C14, C15
1
5.1K
5.1k
R1
1
5.1K
5.1k
R2
Show 7 more
QtyPartRefs
1
330
R3
1
200K
200k
R4
1
40.2K
R5
4
0
R6, R7, R8, R9
1
22K
22k
R10
1
187K
187k
R11
1
12.4K
12.4k
R12

TeenG5 design files

The KiCad project lives in the septentrio-gnss/TeenG5 repository on GitHub; these links point at the commit this page was built from.

TeenG5: common questions

What microcontroller does the TeenG5 use?

The TeenG5 is built around the Untitled_1, from the NXP family.

How big is the TeenG5 PCB?

The TeenG5 measures 62.8 × 27 mm, has 4 copper layers and is 1.598 mm thick.

How many components are on the TeenG5?

39 components, from 27 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the TeenG5 design files?

From the septentrio-gnss/TeenG5 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the TeenG5 design in my own project?

The repository has no license, so all rights stay with septentrio-gnss. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the TeenG5 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug NXP firmware against it before you order a PCB.
