Sensor board-CO2-PA

ZER0-cmd·BOREALIS-1·PCB/sensor-board-CO2-PA/sensor-board-CO2-PA.kicad_pcb

Sensor board-CO2-PA layout, top view — open source board by ZER0-cmd
Simulate this board

About the Sensor board-CO2-PA

Sensor board-CO2-PA is an open source PCB design by ZER0-cmd, published on GitHub under the CERN-OHL-S-2.0 license. It is a 2-layer board measuring 30 × 28.2 mm, with 7 components from 6 distinct parts.

Other key parts include the MAGNETIC POGO CONN.. By type, the board carries 3 resistors, 2 ICs and 2 capacitors.

It belongs with the sensors designs in this gallery.

Sensor board-CO2-PA, from the project README
From the project README

Main components on the Sensor board-CO2-PA

MAGNETIC POGO CONN.

Sensor board-CO2-PA bill of materials (BOM)

7 components, 6 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
MAGNETIC POGO CONN.
U1, U2
1
0.1UF
10microf
C1
1
10NF
0.1uf
C2
1
10K
R1
1
4.7K
10k
R2
1
4.7K
R
R3

Sensor board-CO2-PA design files

The KiCad project lives in the ZER0-cmd/BOREALIS-1 repository on GitHub; these links point at the commit this page was built from.

Sensor board-CO2-PA: common questions

How big is the Sensor board-CO2-PA?

The Sensor board-CO2-PA measures 30 × 28.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Sensor board-CO2-PA?

7 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Sensor board-CO2-PA design files?

From the ZER0-cmd/BOREALIS-1 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Sensor board-CO2-PA design in my own project?

Yes, under the terms of its CERN-OHL-S-2.0 license, which ZER0-cmd chose for the repository.
