Tactile Switch Interface Board

Accessible-AAC·AAC-Devices·peripherals/lightbox/lightbox_pcb_v3/lightbox_pcb.kicad_pcb

Tactile Switch Interface Board layout, top view — open source board by Accessible-AAC

About the Tactile Switch Interface Board

Tactile Switch Interface Board is an open source PCB design by Accessible-AAC, published on GitHub. It is a 2-layer board measuring 26.4 × 108 mm, with 22 components from 7 distinct parts.

Other key parts include the MCP23008-E_P. By type, the board carries 10 resistors, 8 diodes, 1 IC and 1 connector.

From the project

Augmentative and alternative communications device design files based on inexpensive and open source technologies.

These directories contain design files for a lightbox display peripheral, for use with an i2c (green) controller input.

The lightbox is based on a Microchip MCP23008 8-Bit I/O Expander: Datasheet

Tactile Switch Interface Board, from the project README
From the project README

Main components on the Tactile Switch Interface Board

MCP23008-E_P

Tactile Switch Interface Board bill of materials (BOM)

22 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
MCP23008-E_P
U1
1
PJ320A
J1
1
val**
1pin_prototyping
1
PRTR5V0U2X
ESD1
8
LED
D1, D2, D3, D4, D5, D6, D7, D8
8
220
R1, R2, R3, R4, R5, R6, R7, R8
2
10k
R9, R10

Tactile Switch Interface Board design files

The KiCad project lives in the Accessible-AAC/AAC-Devices repository on GitHub; these links point at the commit this page was built from.

Tactile Switch Interface Board: common questions

How big is the Tactile Switch Interface Board?

The Tactile Switch Interface Board measures 26.4 × 108 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Tactile Switch Interface Board?

22 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Tactile Switch Interface Board design files?

From the Accessible-AAC/AAC-Devices repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Tactile Switch Interface Board design in my own project?

The repository has no license, so all rights stay with Accessible-AAC. Use it as a reference, and ask the author before reusing the design.
