Emb ZoneAlarm

About the Emb ZoneAlarm PCB

Emb ZoneAlarm is an open source ESP32 PCB design by ADolbyB, published on GitHub. It is a 2-layer board, with 17 components from 15 distinct parts.

Its main chip is the ESP32_Thing_Plus_C, from the ESP32 family. By type, the board carries 3 LEDs, 3 resistors, 1 module, 1 buzzer and 1 capacitor.

From the project

A collection of Schematics, PCBs and VLSI work on various platforms

This is a collection of similar items I needed for for Project Research. Topics range from KiCad schematics and PCB development, to PSPice and Circuit Development, and finally for VLSI design there is EDA Playground and LTSpice.

- Download OrCad Capture CIS Lite 17.2 Here or Here. - Note that this is the license-free (Lite) version & is posted in the public domain. It does not require a license key or activation. Please use responsibly. - This version of OrCad PSpice was used exclusively for all electronics class simulations. - All of the PSpice projects are my own work.

Emb ZoneAlarm bill of materials (BOM)

17 components, 15 distinct parts.

QtyPartRefs
1
Motor_Servo
M1
1
AudioSensor
Aud1
1
Buzzer
BZ1
1
ESP32_Thing_Plus_C
ESP1
1
Keypad4x4
KP1
1
LCD_I2C_20x4
LCD1
1
PIRSens
PIR1
1
USB 5V
Power1
1
GPIO_2_RGB
RGB1
1
SparkFun_RTC
RTC1
1
Red
LED1
1
Yellow
LED2
1
Clear
LED3
1
1mF each
C1-5
3
470 ohm
R5, R6, R7

Emb ZoneAlarm design files

The KiCad project lives in the ADolbyB/vlsi-spice-pcbs repository on GitHub; these links point at the commit this page was built from.

Emb ZoneAlarm: common questions

What microcontroller does the Emb ZoneAlarm use?

The Emb ZoneAlarm is built around the ESP32_Thing_Plus_C, from the ESP32 family.

How big is the Emb ZoneAlarm PCB?

The Emb ZoneAlarm has 2 copper layers and is 1.6 mm thick.

How many components are on the Emb ZoneAlarm?

17 components, from 15 distinct parts. The full bill of materials is listed on this page.

Where can I download the Emb ZoneAlarm design files?

From the ADolbyB/vlsi-spice-pcbs repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Emb ZoneAlarm design in my own project?

The repository has no license, so all rights stay with ADolbyB. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Emb ZoneAlarm without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
