Circuit for 2nd Milestone

Ammar-Bin-Amir·Poultry_Bot·IoT_Monitoring_System/Circuit/Circuit for 2nd Milestone/Circuit for 2nd Milestone.kicad_pcb

Circuit for 2nd Milestone PCB layout, top view — open source ESP32 board by Ammar-Bin-Amir
Simulate this board

About the Circuit for 2nd Milestone PCB

Circuit for 2nd Milestone is an open source ESP32 PCB design by Ammar-Bin-Amir, published on GitHub. It is a 2-layer board measuring 54.6 × 46.9 mm, with 8 components from 8 distinct parts.

Its main chip is the ESP32-DEVKIT-V1, from the ESP32 family. By type, the board carries 7 connectors and 1 IC.

It belongs with the iot & wireless, robotics & motion and displays & leds designs in this gallery.

From the project

Final Year Project

Poultry Bot is a major technological breakthrough for the poultry industry as it provides solution for utmost problems faced in a poultry farm. The purpose of poultry bot is to completely revolutionize the century old farming practices used till now by introducing the latest technology for 1,190 billion rupees turnover generating sector. The goal is to minimize the biosecurity risk to help improve the production. Further, assisting human to make more informed and better decisions. Poultry bot is an autonomous self-driven robot, monitoring several factors effecting on a poultry farm by…

Circuit for 2nd Milestone, from the project README
From the project README

Main components on the Circuit for 2nd Milestone

ESP32-DEVKIT-V1

Circuit for 2nd Milestone bill of materials (BOM)

8 components, 8 distinct parts.

QtyPartRefs
1
ESP32-DEVKIT-V1
U1
1
NX4832T035
J1
1
DHT22
J2
1
MQ135
J3
1
HC-SR04
J4
1
YF-S201
J5
1
Hw-307b
J6
1
XL4016
J7

Circuit for 2nd Milestone design files

The KiCad project lives in the Ammar-Bin-Amir/Poultry_Bot repository on GitHub; these links point at the commit this page was built from.

Circuit for 2nd Milestone: common questions

What microcontroller does the Circuit for 2nd Milestone use?

The Circuit for 2nd Milestone is built around the ESP32-DEVKIT-V1, from the ESP32 family.

How big is the Circuit for 2nd Milestone PCB?

The Circuit for 2nd Milestone measures 54.6 × 46.9 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Circuit for 2nd Milestone?

8 components, from 8 distinct parts. The full bill of materials is listed on this page.

Where can I download the Circuit for 2nd Milestone design files?

From the Ammar-Bin-Amir/Poultry_Bot repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Circuit for 2nd Milestone design in my own project?

The repository has no license, so all rights stay with Ammar-Bin-Amir. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Circuit for 2nd Milestone without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
