ESP-Sensors
About the ESP-Sensors PCB
ESP-Sensors is an open source ESP8266 PCB design by axello, published on GitHub. It is a 2-layer board measuring 58.4 × 54 mm, with 17 components from 13 distinct parts.
Its main chip is the ESP-12E, from the ESP8266 family. Other key parts include the HT7333. By type, the board carries 5 connectors, 4 resistors, 3 capacitors, 2 ICs and 2 switches.
It belongs with the sensors and iot & wireless designs in this gallery.
From the project
Hodge podge of small electronic designs
Just starting with kicad, this is a hodgepodge of small electronics projects, mostly centered around the ESP8266.
Main components on the ESP-Sensors
ESP-Sensors bill of materials (BOM)
17 components, 13 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ESP-12E | ESP-12E | U1 |
| 1 | HT7333 | SOT89-3_Housing_Handsoldering | U2 |
| 1 | PROG_CONN | Pin_Header_Straight_1x05b | J1 |
| 1 | GPIO | Pin_Header_Straight_1x12 | J2 |
| 1 | SPI | SPI_Header | J3 |
| 1 | +3.3V GND +5V | Pin_Header_Straight_1x04 | J4 |
| 1 | DEEP_SLEEP | Pin_Header_Straight_1x02 | J5 |
| 1 | POT | Potentiometer_Trimmer_Vishay_T73YP_Horizontal | 10K1 |
| 1 | RESET | SW_PUSH_6mm | SW1 |
| 1 | PROG | SW_PUSH_6mm | SW2 |
| 2 | 100nF | C_0805_HandSoldering | C1, C2 |
| 1 | 100µF | c_elec_6.3x7.7 | C3 |
| 4 | 10K | R_0805_HandSoldering | R1, R2, R3, R4 |
ESP-Sensors design files
The KiCad project lives in the axello/kicad repository on GitHub; these links point at the commit this page was built from.
ESP-Sensors: common questions
What microcontroller does the ESP-Sensors use?
The ESP-Sensors is built around the ESP-12E, from the ESP8266 family.
How big is the ESP-Sensors PCB?
The ESP-Sensors measures 58.4 × 54 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the ESP-Sensors?
17 components, from 13 distinct parts. The full bill of materials is listed on this page.
Where can I download the ESP-Sensors design files?
From the axello/kicad repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the ESP-Sensors design in my own project?
The repository has no license, so all rights stay with axello. Use it as a reference, and ask the author before reusing the design.
Can I test firmware for the ESP-Sensors without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
