Smartbag optics

claudiofin·smartbag·hardware/smartbag_optics.kicad_pcb

Smartbag optics PCB layout, top view — open source board by claudiofin
Simulate this board

About the Smartbag optics PCB

Smartbag optics is an open source PCB design by claudiofin, published on GitHub under the MIT license. It is a 2-layer board measuring 134 × 12 mm, with 13 components from 7 distinct parts.

Other key parts include the VL53L1CXV0FY/1. By type, the board carries 4 diodes, 4 resistors, 2 connectors, 2 capacitors and 1 IC.

It belongs with the sensors designs in this gallery.

From the project

Tagless smart insert for a handbag: recognises its contents with an IR camera, 60 GHz radar and a 96-taxel FSR floor. PCB, CAD, renders and films all generated by script (KiCad -> CadQuery -> Blender).

A removable smart insert for a handbag that recognises what is inside it — without putting a tag on anything.

Everything in this repo is generated by script: the PCB, the CAD, the renders, the films. One command runs the whole chain, from KiCad to a finished MP4.

This is a design study. Some of it is now checked by machine; none of it has been built.

⚠️ The last two lines are printed on every run on purpose — and they are the two findings that rewrote the board. The feed loss deleted the 60 GHz copper and split one transceiver into two sensors; the charging analysis added a thermistor and…

Smartbag optics, from the project README
From the project README

Main components on the Smartbag optics

VL53L1CXV0FY/1

Smartbag optics bill of materials (BOM)

13 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
VL53L1CXV0FY/1
VL53L1X
STMicroelectronics
U10
1
FFC to insert, 12 way
J10
1
camera module, 6 way
JST
J11
4
VSMY1850X01 850nm
D1, D2, D3, D4
1
100n X7R
C1
1
4u7 X5R 10V
C2
4
51R 1%
R1, R2, R3, R4

Smartbag optics design files

The KiCad project lives in the claudiofin/smartbag repository on GitHub; these links point at the commit this page was built from.

Smartbag optics: common questions

How big is the Smartbag optics PCB?

The Smartbag optics measures 134 × 12 mm, has 2 copper layers and is 0.2 mm thick.

How many components are on the Smartbag optics?

13 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Smartbag optics design files?

From the claudiofin/smartbag repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Smartbag optics design in my own project?

Yes, under the terms of its MIT license, which claudiofin chose for the repository.
