Scbs pico PCB layout, top view — open source RP2040/RP2350 board by CoolNamesAllTaken

About the Scbs pico PCB

Scbs pico is an open source RP2040/RP2350 PCB design by CoolNamesAllTaken, published on GitHub. It is a 2-layer board measuring 60 × 60 mm, with 50 components from 28 distinct parts.

Its main chip is the SC0915, from the RP2040/RP2350 family. Other key parts include the TLV9062IDR and BPC-817S ( C BIN ). By type, the board carries 29 resistors, 9 capacitors, 4 transistors, 3 ICs, 3 diodes and 2 connectors.

It belongs with the power & battery designs in this gallery.

From the project

Single Cell Battery Simulator for testing a BMS.

Cellsim 4S is a low-current battery pack simulator that simulates four battery cells in series. Each cell has a settable output voltage between 2.5-4.5V and a readable output current. Communication is done over a 9600 baud UART link using a custom serial protocol.

SCBS Pico is a single battery cell simulator that can be daisy chained with other devices of the same type in order to build a full simulated battery pack. It is the basic building block of the CELLSIM 4S.

Scbs pico, from the project README
From the project README

Main components on the Scbs pico

TLV9062IDRBPC-817S ( C BIN )SC0915

Scbs pico bill of materials (BOM)

50 components, 28 distinct parts.

QtyPartRefs
1
TLV9062IDR
TLV9062xD
U1
1
BPC-817S ( C BIN )
PC817
U2
1
SC0915
Pico
U3
1
PN2907ATF
2N2907
Q1
1
2N7002
Q2
2
MMBT3904
Q3, Q4
1
PREC006SBAN-M71RC
Conn_01x06_Male
J1
1
4048
Conn_ARM_JTAG_SWD_10
J2
3
1N4148W-TP
1N4148
D1, D2, D3
2
1nF
C1, C7
3
DNP
C2, C5, C6
1
1uF
C3
3
0.1uF
C4, C8, C9
2
2M
R1, R20
3
1k
R2, R14, R26
2
3k3
R3, R4
1
750R
R5
3
390R
R6, R23, R24
1
0R
R7
3
3.9R 1% 0805
R8, R9, R10
Show 8 more
QtyPartRefs
2
10M
R11, R15
1
4.3R 1% 0805
R12
1
100R
R13
1
DNP
R16
2
510k 1%
R17, R18
1
1R
R19
2
8.2M 1%
R21, R22
4
10k
R25, R27, R28, R30

Scbs pico design files

The KiCad project lives in the CoolNamesAllTaken/scbs repository on GitHub; these links point at the commit this page was built from.
