The Wozblaster Reloaded
cristianoag·wozblaster·hardware/reloaded_v1.1/MSX OPL4 Wozblaster.kicad_pcb
About the The Wozblaster Reloaded PCB
The Wozblaster Reloaded is an open source PCB design by cristianoag, published on GitHub. It is a 2-layer board measuring 100 × 64.8 mm, with 46 components from 22 distinct parts.
Other key parts include the YMF278B-F, YAC513-M, 27C160, GAL16V8D and LF347. By type, the board carries 23 capacitors, 13 resistors, 8 ICs, 1 transistor and 1 connector.
It belongs with the audio and retro computing designs in this gallery.
From the project
Repository to host source files for the Wozblaster Reloaded
At its core is the OPL4 (FM Operator Type-L4) sound chip, which was developed by Yamaha and used in a variety of electronic musical instruments and computer sound cards.
With the WozBlaster OPL4 cartridge, MSX computer users can enjoy high-quality sound and create complex musical arrangements with ease.
The WozBlaster cartridge is an external sound device designed for the MSX platform. It is a clone of the Moonsound and allows access to the advanced capabilities of the OPL4 sound chip for MSX games and other OPL4-compatible music software. The cartridge was originally designed by Gustavo…

Main components on the The Wozblaster Reloaded
The Wozblaster Reloaded bill of materials (BOM)
46 components, 22 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | YMF278B-F | 80-QFP | IC2 |
| 1 | YAC513-M | 16SOP | IC3 |
| 1 | 27C160 27c160 | DIL42 | IC4 |
| 1 | GAL16V8D | DIL20 | IC5 |
| 2 | LF347 | SO14-2 | U2, U3 |
| 2 | KM684000ALG | SOP32L | U4, U5 |
| 1 | 33.8688 | HC49_S | Q1 |
| 1 | PJ-307 | PJ-307 | J1 |
| 1 | 10PF 10pF | C2.5-2 | C1 |
| 2 | 330NF 330nF | C2.5-2 | C2, C12 |
| 4 | 2.2NF 2.2nF | C2.5-2 | C3, C5, C6, C7 |
| 2 | 15NF 15nF | C2.5-2 | C4, C11 |
| 1 | 10uF 16V | E2,5-5 | C8 |
| 2 | 22uF 16v | E2,5-5 | C9, C10 |
| 7 | 100NF 100nF | C2.5-2 | C13, C16, C17, C18, C19, C20, C23 |
| 2 | 12PF 12pF | C2.5-2 | C14, C15 |
| 1 | 4.7uF 16v | E2,5-5 | C21 |
| 1 | D 470uF 16V (Tantalum) | D_7343-31R | C22 |
| 2 | 360 | 0204_7 | R1, R2 |
| 8 | 1k | 0204_7 | R3, R4, R5, R6, R8, R10, R11, R12 |
Show 2 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | 100K 100k | 0204_7 | R7, R9 |
| 1 | 3.3K 3.3k | 0204_7 | R13 |
The Wozblaster Reloaded design files
The KiCad project lives in the cristianoag/wozblaster repository on GitHub; these links point at the commit this page was built from.
The Wozblaster Reloaded: common questions
How big is the The Wozblaster Reloaded PCB?
The The Wozblaster Reloaded measures 100 × 64.8 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the The Wozblaster Reloaded?
46 components, from 22 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the The Wozblaster Reloaded design files?
From the cristianoag/wozblaster repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the The Wozblaster Reloaded design in my own project?
The repository has no license, so all rights stay with cristianoag. Use it as a reference, and ask the author before reusing the design.
