Rowwy PCB layout, top view — open source board by devisunofficial

About the Rowwy PCB

Rowwy is an open source PCB design by devisunofficial, published on GitHub. It is a 2-layer board measuring 66.6 × 32.8 mm, with 42 components from 7 distinct parts.

Other key parts include the Motor Driver and AP63203WU-7. By type, the board carries 26 connectors, 12 capacitors, 3 ICs and 1 inductor.

It belongs with the iot & wireless, power & battery and sensors designs in this gallery.

Rowwy, from the project README
From the project README

Main components on the Rowwy

Motor DriverAP63203WU-7

Rowwy bill of materials (BOM)

42 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
Motor Driver
TOSHIBA(东芝)
U1, U3
1
AP63203WU-7
DIODES(美台)
U2
26
Conn_01x01_Pin
J1, J2, J3, J4, J5, J6, J7, J8 +18
1
4.7uH
L1
5
10uF
C1, C5, C7, C9, C11
5
100nF
C2, C6, C8, C10, C12
2
22uF
C3, C4

Rowwy design files

The KiCad project lives in the devisunofficial/Rowwy repository on GitHub; these links point at the commit this page was built from.

Rowwy: common questions

How big is the Rowwy PCB?

The Rowwy measures 66.6 × 32.8 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Rowwy?

42 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Rowwy design files?

From the devisunofficial/Rowwy repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Rowwy design in my own project?

The repository has no license, so all rights stay with devisunofficial. Use it as a reference, and ask the author before reusing the design.
