CapArray JYC RM2023 V0.2
About the CapArray JYC RM2023 V0.2 PCB
CapArray JYC RM2023 V0.2 is an open source STM32 PCB design by evil0knight, published on GitHub. It is a 4-layer board measuring 59 × 90 mm, with 114 components from 37 distinct parts.
Its main chip is the STM32F334R8TX, from the STM32 family. Other key parts include the INA240A1PW, GS8332-SR, SIT1042/3, RY8411 and RS3236. By type, the board carries 67 resistors, 13 diodes, 12 capacitors, 11 ICs and 11 transistors.
From the project
C++,KICAD，H桥升降压，拟合，测电流电阻
11.1 现在的问题是电容端口短路，初步怀疑是原件选型错误，解决方法：加上了群里的同学一起讨论，和队里的研究生一起排查，看研究生的学习笔记，学习 C++
11.13 GAME WILL OVER，lucky，终于冲放电成功了，不报错，不过另一个的上板电流采样芯片可能坏了，等快递
11.18 第二个也做出来了，一开始错误的原因是底盘电流检测芯片选型错误，要 INA240PW1 才是对的，INA240PW2 的增益是不同的 这如此种种也不过如此啊
11.20 上车正常，最终效果：可以成功存储能量，要用的时候再输出，根据功率自动选择存储还是释放，功率闭环 + 缓冲能量闭环
Main components on the CapArray JYC RM2023 V0.2
CapArray JYC RM2023 V0.2 bill of materials (BOM)
114 components, 37 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | ~ | SOT-23-5 | U1, U3 |
| 3 | INA240A1PW ~ | SOT-23-5 | U2, U4, U5 |
| 1 | GS8332-SR ~ | SOT-23-5 | U6 |
| 1 | STM32F334R8TX ~ | SOT-23-5 | U7 |
| 1 | SIT1042/3 ~ | SOT-23-5 | U8 |
| 2 | RY8411 ~ | SOT-23-5 | U9, U11 |
| 1 | RS3236 ~ | SOT-23-5 | U10 |
| 1 | AO3400A Q_NMOS_GDS | TO-252-2 | Q1 |
| 10 | Q_NMOS_GDS | TO-252-2 | Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9 +2 |
| 3 | DSS34 LED | LED_0603_1608Metric | D1, D2, D3 |
| 1 | SMF3.3A LED | LED_0603_1608Metric | D4 |
| 1 | SMAJ28A LED | LED_0603_1608Metric | D5 |
| 5 | LED | LED_0603_1608Metric | D6, D7, D8, D9, D12 |
| 2 | SMF10A LED | LED_0603_1608Metric | D10, D11 |
| 1 | SMCJ30A | D_SMC | D13 |
| 4 | 100N 50F | CP_Radial_D18.0mm_P7.50mm | C1, C8, C10, C11 |
| 3 | 50F | CP_Radial_D18.0mm_P7.50mm | C2, C6, C7 |
| 3 | 10U 50F | CP_Radial_D18.0mm_P7.50mm | C3, C5, C9 |
| 1 | 20P 50F | CP_Radial_D18.0mm_P7.50mm | C4 |
| 1 | 100N 2200uf | CP_Radial_D18.0mm_P7.50mm | C12 |
Show 17 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 10 | 33R 1k | R_0603_1608Metric | R1, R2, R3, R4, R22, R23, R24, R26 +2 |
| 1 | 33R R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R5 |
| 3 | 10K R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R6, R40, R42 |
| 2 | 2.2K R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R7, R11 |
| 2 | 2.2K 1k | R_0603_1608Metric | R8, R10 |
| 2 | 2MR 1k | R_0603_1608Metric | R9, R15 |
| 1 | 2MR R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R12 |
| 21 | R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R13, R17, R19, R33, R34, R35, R43, R44 +13 |
| 16 | 1k | R_0603_1608Metric | R14, R16, R20, R29, R30, R31, R32, R46 +8 |
| 1 | 68R R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R18 |
| 1 | 68R 1k | R_0603_1608Metric | R21 |
| 1 | 120R 1k | R_0603_1608Metric | R25 |
| 1 | 10K 1k | R_0603_1608Metric | R28 |
| 2 | 120R R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R36, R38 |
| 1 | 118K R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R39 |
| 1 | 53.6K R300 | R_2512_6332Metric_Pad1.40x3.35mm_HandSolder | R41 |
| 1 | 5.1k | R_0603_1608Metric | R52 |
CapArray JYC RM2023 V0.2 design files
The KiCad project lives in the evil0knight/RM_SUPERCAP_JSU repository on GitHub; these links point at the commit this page was built from.
- LayoutJSU_V2/cap_array_hardware/cap_array_hardware/capArray_JYC_RM2023_V0.2.kicad_pcb
- SchematicJSU_V2/cap_array_hardware/cap_array_hardware/capArray_JYC_RM2023_V0.2.kicad_sch
- BOMJSU_V2/SuperCapacitorController-master(2)/NEWSuperCapacitorController-master/hardware/SuperCap2024_Control_V1.1R_F3_ISOPWR/bom.csv
CapArray JYC RM2023 V0.2: common questions
What microcontroller does the CapArray JYC RM2023 V0.2 use?
The CapArray JYC RM2023 V0.2 is built around the STM32F334R8TX, from the STM32 family.
How big is the CapArray JYC RM2023 V0.2 PCB?
The CapArray JYC RM2023 V0.2 measures 59 × 90 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the CapArray JYC RM2023 V0.2?
114 components, from 37 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the CapArray JYC RM2023 V0.2 design files?
From the evil0knight/RM_SUPERCAP_JSU repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the CapArray JYC RM2023 V0.2 design in my own project?
The repository has no license, so all rights stay with evil0knight. Use it as a reference, and ask the author before reusing the design.
Can I test firmware for the CapArray JYC RM2023 V0.2 without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
