Default
About the Default PCB
Default is an open source PCB design by glovepost, published on GitHub under the MIT license. It is a 4-layer board measuring 45 × 167 mm, with 137 components from 55 distinct parts.
Other key parts include the TAS5825MRHBR, SN74LVC1G07DBVR, SMTSO2515CTJ, TPS54560DDAR and STUSB4500QTR. By type, the board carries 60 capacitors, 40 resistors, 13 ICs, 6 diodes, 5 inductors and 2 transistors.
From the project
KiCAD EDA automatic component placement tool
atoplace is an intelligent orchestration layer for PCB design that bridges the gap between schematic and physical layout. It automates the tedious 80% of design—placement optimization and DFM validation—while strictly adhering to "Manhattan" aesthetics and Signal Integrity (SI) best practices.
Designed to work seamlessly with atopile and KiCad.
PCB layout automation has historically been "black box" and "messy"—producing organic, unreadable layouts that professional engineers reject. atoplace takes a different approach:
Main components on the Default
Default bill of materials (BOM)
137 components, 55 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | TAS5825MRHBR Texas Instruments | VQFN-32_L5.0-W5.0-P0.50-TL-EP | U1 |
| 1 | SN74LVC1G07DBVR Texas Instruments | SOT-23-5_L3.0-W1.7-P0.95-LS2.8-BR | U2 |
| 4 | SMTSO2515CTJ Sinhoo | SMD_BD5.6-D4.1 | U3, U4, U5, U6 |
| 1 | TPS54560DDAR Texas Instruments | SOIC-8_L5.0-W4.0-P1.27-LS6.0-BL-EP2.0 | U7 |
| 1 | STUSB4500QTR STMicroelectronics | QFN-24_L4.0-W4.0-P0.50-BL-EP2.8 | U20 |
| 2 | B02B-XASK-1-A(LF)(SN) JST Sales America | CONN-TH_B02B-XASK-1-A-LF-SN | U21, U22 |
| 1 | HC-TYPE-C-24P-VS9.3-5A-F1.1-04 HCTL | USB-C-SMD_HC-TYPE-C-24P-VS9.3-5A-F1.1-04 | U23 |
| 1 | ADAU1452WBCPZ Analog Devices | LFCSP-72_L10.0-W10.0-P0.50-LS10.2-BL-EP5.3 | U24 |
| 1 | TLV75901PDRVR Texas Instruments | WSON-6_L2.0-W2.0-P0.65-TL-EP | U25 |
| 1 | AP30P30Q ALLPOWER(ShenZhen Quan Li Semiconductor) | PDFN3333-8_L3.1-W3.2-P0.65-LS3.4-BL | Q1 |
| 1 | PBSS5350X,115 Nexperia | SOT-89-3_L4.5-W2.5-P1.50-LS4.1-TR | Q2 |
| 1 | TXM12.288M0004322FBCDO00T TAE | CRYSTAL-SMD_4P-L3.2-W2.5-BL-2 | X1 |
| 2 | DF40C-100DS-0.4V(51) HRS(Hirose) | CONN-SMD_DF40C-100DS-0.4V-51 | CN1, CN2 |
| 1 | 1-2328702-0 TE Connectivity | FPC-SMD_10P-P0.50_HDGC_0.5K-HX-10PWB | FPC1 |
| 3 | PZ254-2-04-S HCTL | HDR-SMD_8P-P2.54-V-M-R2-C4-LS7.4 | HDR1, HDR2, HDR3 |
| 1 | HR911130A HANRUN(Zhongshan HanRun Elec) | RJ45-TH_HR911130A | RJ1 |
| 2 | TS-1101-C-W XKB Connectivity | SW-SMD_L6.0-W3.3-LS8.0 | SW1, SW2 |
| 1 | U262-241N-4BV64 XKB Connectivity | USB-C-SMD_TYC-324G | USB1 |
| 1 | 19-213/Y2C-CQ2R2L/3T(CY) Everlight Elec | LED0603-RD-YELLOW | D1 |
| 1 | KT-0603G Hubei KENTO Elec | LED0603-RD | D2 |
Show 35 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | STPS340U STMicroelectronics | SMB_L4.6-W3.6-LS5.3-RD | D3 |
| 1 | ESDA25W STMicroelectronics | SOT-323-3_L2.1-W1.3-P1.32-LS2.1-BR | D4 |
| 2 | ESDA25P35-1U1M STMicroelectronics | DFN1610-2_L1.6-W1.0-P1.05-RD | D5, D6 |
| 4 | FXL0630-100-M 10µH ±20% 4.5A 68mΩ cjiang(Changjiang Microelectronics Tech) | IND-SMD_L7.3-W6.8 | L1, L2, L3, L4 |
| 1 | SWPA8040S5R6NT Sunlord | IND-SMD_L8.0-W8.0_SWPA8040S | L5 |
| 7 | CL05A105KA5NQNC 1µF ±10% 25V X5R Samsung Electro-Mechanics | C0402 | C1, C4, C19, C21, C22, C31, C32 |
| 1 | CL10A475KO8NNNC 4.7µF ±10% 16V X5R Samsung Electro-Mechanics | C0603 | C2 |
| 15 | CL05B104KO5NNNC 100nF ±10% 16V X7R Samsung Electro-Mechanics | C0402 | C3, C33, C38, C39, C40, C41, C42, C43 +7 |
| 4 | CC0603KRX7R9BB474 470nF ±10% 50V X7R YAGEO | C0603 | C5, C6, C9, C10 |
| 4 | CC0805KKX7R9BB684 680nF ±10% 50V X7R YAGEO | C0805 | C7, C8, C11, C12 |
| 10 | CL21A106KAYNNNE 10µF ±10% 25V X5R Samsung Electro-Mechanics | C0805 | C13, C14, C15, C16, C17, C18, C34, C35 +2 |
| 1 | CL05B104KB54PNC 100nF ±10% 50V X7R Samsung Electro-Mechanics | C0402 | C20 |
| 1 | CC0402JRX7R9BB472 4.7nF ±5% 50V X7R YAGEO | C0402 | C23 |
| 1 | CC0402JRNPO9BN200 20pF ±5% 50V C0G YAGEO | C0402 | C24 |
| 3 | GRM21BR61H106KE43L 10µF ±10% 50V X5R Murata Electronics | C0805 | C25, C26, C27 |
| 4 | CL21A226MAQNNNE 22µF ±20% 25V X5R Samsung Electro-Mechanics | C0805 | C28, C29, C52, C60 |
| 1 | CL10A475KL8NRNC 4.7µF ±10% 35V X5R Samsung Electro-Mechanics | C0603 | C30 |
| 2 | 0402CG150J500NT 15pF ±5% 50V C0G FH(Guangdong Fenghua Advanced Tech) | C0402 | C48, C49 |
| 1 | CC0603KRX7R9BB562 5.6nF ±10% 50V X7R YAGEO | C0603 | C50 |
| 1 | CC0603JRNPO9BN151 150pF ±5% 50V C0G YAGEO | C0603 | C51 |
| 4 | RVT1H470M0607 Honor Elec | CAP-SMD_BD6.3-L6.6-W6.6-FD | C56, C57, C58, C59 |
| 3 | 0402WGF4701TCE 4.7kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R1, R15, R16 |
| 8 | 0402WGF1002TCE 10kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R2, R3, R4, R5, R35, R37, R40, R41 |
| 2 | 0402WGF2001TCE 2kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R6, R7 |
| 2 | 0402WGF4700TCE 470Ω ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R8, R9 |
| 1 | 0402WGF2372TCE 23.7kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R10 |
| 15 | 0402WGF1001TCE 1kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R11, R12, R14, R17, R24, R25, R26, R27 +7 |
| 1 | 0402WGF1623TCE 162kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R13 |
| 1 | 0402WGF1003TCE 100kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R18 |
| 1 | 0402WGF2202TCE 22kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R19 |
| 2 | 0402WGF1000TCE 100Ω ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R20, R21 |
| 1 | 0603WAF0000T5E 0Ω 100mW UNI-ROYAL(Uniroyal Elec) | R0603 | R22 |
| 1 | 0603WAF4301T5E 4.3kΩ ±1% 100mW UNI-ROYAL(Uniroyal Elec) | R0603 | R23 |
| 1 | 0402WGF4702TCE 47kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R36 |
| 1 | 0402WGF5492TCE 54.9kΩ ±1% 62.5mW UNI-ROYAL(Uniroyal Elec) | R0402 | R38 |
Default design files
The KiCad project lives in the glovepost/atoplace repository on GitHub; these links point at the commit this page was built from.
Default: common questions
How big is the Default PCB?
The Default measures 45 × 167 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the Default?
137 components, from 55 distinct parts. The full bill of materials is listed on this page.
Where can I download the Default design files?
From the glovepost/atoplace repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Default design in my own project?
Yes, under the terms of its MIT license, which glovepost chose for the repository.
