Dual Power Supply

HighCarlSagan·Dual_Power_Supply

Dual Power Supply PCB layout, top view — open source board by HighCarlSagan
Simulate this board

About the Dual Power Supply PCB

Dual Power Supply is an open source PCB design by HighCarlSagan, published on GitHub under the Custom license license. It is a 4-layer board measuring 150 × 80 mm, with 57 components from 17 distinct parts.

By type, the board carries 26 resistors, 24 capacitors and 4 connectors.

It belongs with the power & battery, sensors and dev boards & breakouts designs in this gallery.

From the project

Universal power supply with 5V and 3v3 output, upto 60 Watts total. 6A on each rail.

A compact mains-input dual-output bench supply built around an isolated AC-DC brick and two integrated buck modules. Provides clean, regulated 5 V and 3.3 V rails for hobby electronics — bench bringup, MCU dev boards, sensors, LEDs, and small actuator loads.

I wanted a single, always-on bench supply that I could leave plugged in and tap into for anything I'm prototyping: ESP32s, Pis, sensor breakouts, the Telegram-controlled lights board, whatever.

Dual Power Supply, from the project README
From the project README

Dual Power Supply bill of materials (BOM)

57 components, 17 distinct parts — part numbers from the project's BOM.

QtyPartRefs
4
1715048
Screw_Terminal_01x04
Phoenix Contact
J1, J2, J3, J4
1
IRM-60-12
IRM-60-15
MEAN WELL USA Inc.
PS1
2
TLVM14406RCHR
Texas Instruments
PS2, PS3
4
C1210C106M3RACTU
10u_50V_1210
KEMET
C1, C2, C13, C14
4
CL10B473KO8NNNC
47n_16V_0603
KEMET
C3, C10, C15, C22
2
EEV107M050S9MAA
100u_50V_1210
KEMET
C4, C16
8
GRM32ER71E226ME15L
22u_25V_1210
KEMET
C5, C6, C9, C11, C17, C18, C21, C23
2
C0603C473K3RACTU
2.2n_25V_1210
KEMET
C7, C19
4
C1210C105K3RACTU
1u_25V_1210
KEMET
C8, C12, C20, C24
8
CRCW060310K0FKEAHP
10k_0.21W_0603
Vishay Dale
R1, R5, R10, R11, R14, R18, R23, R24
4
CRCW060331K6FKEAC
31.6k_0.21W_0603
Vishay Dale
R2, R7, R15, R20
2
CRCW0603100RFKEAHP
100_0.21W_0603
Vishay Dale
R3, R16
2
CRCW060352K3FKEAC
52.3k_0.21W_0603
Vishay Dale
R4, R17
4
CRCW06030000Z0EAHP
0_0.21W_0603
Vishay Dale
R6, R13, R19, R26
2
CRCW06037K15FKEAHP
7.15k_0.21W_0603
Vishay Dale
R8, R21
2
CRCW06039K53FKEAC
9.53k_0.21W_0603
Vishay Dale
R9, R22
2
CRCW060311K0FKEAC
11k_0.21W_0603
Vishay Dale
R12, R25

Dual Power Supply design files

The KiCad project lives in the HighCarlSagan/Dual_Power_Supply repository on GitHub; these links point at the commit this page was built from.

Dual Power Supply: common questions

How big is the Dual Power Supply PCB?

The Dual Power Supply measures 150 × 80 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the Dual Power Supply?

57 components, from 17 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Dual Power Supply design files?

From the HighCarlSagan/Dual_Power_Supply repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Dual Power Supply design in my own project?

It is published under Custom license, which limits how it may be reused; read the license before building on it.
