Practice-1

About the Practice-1 PCB

Practice-1 is an open source PCB design by JesusRamiroGarzaHdz, published on GitHub. It is a board, with 63 components from 16 distinct parts.

Other key parts include the MAX232 and MCP9700A. By type, the board carries 18 resistors, 10 jumpers, 9 diodes, 8 switches, 5 capacitors and 2 ICs.

It belongs with the sensors designs in this gallery.

From the project

The student will make the schematic design of a minimum card system, which he/she will work with throughout the semester. The minimum system contains following elements: potentiometer and thermistor ICs, serial port, power connector, LCD , push buttons, LEDs, and keyboard connect

The student will make the schematic design of a minimum card system, which he/she will work with throughout the semester. The minimum system contains following elements: potentiometer and thermistor ICs, serial port, power connector, LCD , push buttons, LEDs, and keyboard connections. The students will use the design software ‘Kicad’ for the entire design (schematic and layout.)

Main components on the Practice-1

MAX232MCP9700A

Practice-1 bill of materials (BOM)

63 components, 16 distinct parts.

QtyPartRefs
1
MAX232
U1
1
MCP9700A
U3
1
F09HP
X2
4
PINHD-1X8
JP2, JP3, JP11, JP14
1
PINHD-1X2
JP5
3
PINHD-1X3
JP9, JP10, JP15
1
PINHD-1X14
JP12
1
PINHD-1X11
JP13
3
10k
RV1, RV2, RV3
7
470
RV4, RV5, RV6, RV7, RV8, RV9, RV10
8
DTS-6
S1, S2, S3, S4, S5, S6, S7, S8
9
LED
D1, D2, D3, D4, D5, D6, D7, D8 +1
5
CP
C6, C7, C9, C10, C11
2
470
R3, R11
8
1k
R12, R13, R14, R15, R16, R17, R18, R19
8
4.7k
R20, R21, R22, R23, R24, R25, R26, R27

Practice-1 design files

The KiCad project lives in the JesusRamiroGarzaHdz/Practice-1 repository on GitHub; these links point at the commit this page was built from.

Practice-1: common questions

How many components are on the Practice-1?

63 components, from 16 distinct parts. The full bill of materials is listed on this page.

Where can I download the Practice-1 design files?

From the JesusRamiroGarzaHdz/Practice-1 repository on GitHub, which has the schematic and a netlist; the links under Design files point to each one.

Can I use the Practice-1 design in my own project?

The repository has no license, so all rights stay with JesusRamiroGarzaHdz. Use it as a reference, and ask the author before reusing the design.
