2023 2024 mini project Junjiang Thang Stephane PCB layout, top view — open source board by JunjiangGuo

About the 2023 2024 mini project Junjiang Thang Stephane PCB

2023 2024 mini project Junjiang Thang Stephane is an open source PCB design by JunjiangGuo, published on GitHub. It is a 2-layer board measuring 68.6 × 53.3 mm, with 22 components from 18 distinct parts.

Other key parts include the LTC1050, Gas_sensor and MCP41100. By type, the board carries 8 resistors, 5 connectors, 4 capacitors, 3 ICs, 1 transistor and 1 switch.

It belongs with the sensors designs in this gallery.

From the project

rxPin and txPin are defined for the serial connection to the LoRa module, allowing for data transmission and reception.

rxPin and txPin are defined for the serial connection to the LoRa module, allowing for data transmission and reception.

A virtual serial port (loraSerial) is created for communication with the LoRa module, using the defined rxPin and txPin. The built-in Serial port is used for debugging.

The frequency plan for LoRaWAN communication is set to TTNFPEU868 which is suitable for Europe. The TheThingsNetwork object is initialized with the LoRa and debug serial connections.

2023 2024 mini project Junjiang Thang Stephane, from the project README
From the project README

Main components on the 2023 2024 mini project Junjiang Thang Stephane

LTC1050Gas_sensorMCP41100

2023 2024 mini project Junjiang Thang Stephane bill of materials (BOM)

22 components, 18 distinct parts.

QtyPartRefs
1
LTC1050
U1
1
Gas_sensor
U2
1
MCP41100
U3
1
IRF520
Q1
1
Power
J1
1
Digital/PWM
J2
1
Analog
J3
1
Digital/PWM
J4
1
LORA_STACK
J7
1
SW_SPDT
SW1
3
100n
C1, C2, C4
1
1u
C3
1
10k
R1
2
100k
R2, R3
2
1k
R4, R5
1
100
R6
1
1k
R7
1
10k
R8

2023 2024 mini project Junjiang Thang Stephane design files

The KiCad project lives in the JunjiangGuo/2023_2024_mini_project_Junjiang_Thang_Stephane repository on GitHub; these links point at the commit this page was built from.

2023 2024 mini project Junjiang Thang Stephane: common questions

How big is the 2023 2024 mini project Junjiang Thang Stephane PCB?

The 2023 2024 mini project Junjiang Thang Stephane measures 68.6 × 53.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the 2023 2024 mini project Junjiang Thang Stephane?

22 components, from 18 distinct parts. The full bill of materials is listed on this page.

Where can I download the 2023 2024 mini project Junjiang Thang Stephane design files?

From the JunjiangGuo/2023_2024_mini_project_Junjiang_Thang_Stephane repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the 2023 2024 mini project Junjiang Thang Stephane design in my own project?

The repository has no license, so all rights stay with JunjiangGuo. Use it as a reference, and ask the author before reusing the design.
