Super DMG CPU is an open source PCB design by kamicane, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 83 × 78.5 mm, with 42 components from 21 distinct parts.
Other key parts include the LPW5209B5F-21. By type, the board carries 21 capacitors, 11 resistors, 1 IC, 1 crystal, 1 connector and 1 switch.
It belongs with the audio, power & battery and retro computing designs in this gallery.
From the project
A Recreation of the Original Game Boy, With a Few Modern Twists
Super DMG CPU works with both IPS and DOT MATRIX LCD boards.
The schematic is largely based on the work done by bit 9.
I used Gekkio KiCAD libs for a few symbols (cpu, ram, cart connector, link port). The specialized footprints were traced by me using fusion 360, using these scans by bit 9 as a reference.
v1.8 and below have an error with the Link Port, where the footprint was flipped (sigh). If you have a v1.8 or below please don't use the link port, as it might damage the other Game Boy! This was fixed in later versions.
Main components on the Super DMG CPU
Super DMG CPU bill of materials (BOM)
42 components, 21 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LPW5209B5F-21 LOWPOWER | SOT-23-5_L2.9-W1.6-P0.95-LS2.8-BL | U5 |
| 1 | 4.194304 MHz | HC-49S | X1 |
| 1 | BATTERY HCTL(华灿天禄) | CONN-TH_2P-P1.25_HCTL_HC-1.25-2AW | CN4 |
| 4 | BAV99-7-F | SOT-23-3_L2.9-W1.3-P1.90-LS2.4-BR | DA1, DA2, DA3, DA4 |
| 1 | DPDT | DMGB_POWER_SWITCH | SW1 |
| 1 | CHARGE_PORT | USB_C_16p | USB1 |
| 1 | 1N414 | D_SOD-123 | D2 |
| 2 | 100µf | CP_EIA-3528-12_Kemet-T_Pad1.50x2.35mm_HandSolder | C1, C23 |
| 2 | 1µF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C3, C4 |
| 2 | 10µF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C5, C6 |
| 3 | 47NF 47nF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C7, C8, C9 |
| 3 | 100NF 100nF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C10, C24, C25 |
| 3 | 10NF 10nF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C12, C13, C14 |
| 4 | 100PF 100pF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C16, C17, C18, C19 |
| 2 | 27PF 27pF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C21, C22 |
| 4 | 220Ω | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R1, R2, R3, R4 |
| 2 | 510Ω | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R5, R6 |
| 1 | 180kΩ | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R7 |
| 1 | 1MΩ | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R8 |
| 1 | 10kΩ | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R9 |
Show 1 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | 5.1kΩ | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R10, R11 |
Super DMG CPU design files
The KiCad project lives in the kamicane/Super-DMG-01 repository on GitHub; these links point at the commit this page was built from.
Super DMG CPU: common questions
How big is the Super DMG CPU PCB?
The Super DMG CPU measures 83 × 78.5 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Super DMG CPU?
42 components, from 21 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Super DMG CPU design files?
From the kamicane/Super-DMG-01 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Super DMG CPU design in my own project?
Yes, under the terms of its CC-BY-SA-4.0 license, which kamicane chose for the repository.
