Models heart PCB layout, top view — open source ESP8266 board by KushlaVR
Simulate this board

About the Models heart PCB

Models heart is an open source ESP8266 PCB design by KushlaVR, published on GitHub under the GPL-3.0 license. It is a 4-layer board measuring 29.9 × 32 mm, with 63 components from 28 distinct parts.

Its main chip is the C89297, from the ESP8266 family. Other key parts include the C16581, C917079, C84681, C880752 and C50506. By type, the board carries 28 resistors, 15 capacitors, 9 transistors, 6 ICs, 3 diodes and 1 connector.

It belongs with the iot & wireless and power & battery designs in this gallery, and the repository also holds 1 earlier revision of it.

From the project

Плата для керування електронікою моделі (статичної або рухомої)

Плата для керування електронікою моделі (статичної або рухомої)

Можливості: Керування через WIFI з телефона або ПК 5 незалежних каналів (світлодіоди/сервомотори) 1 Н-міст для підключення мотора (піковий струм до 3А) Вмонтована BMS 1S та контроллер заряду Li-Ion акумулятора з індикацією заряду Вмикання/вимикання 1 кнопкою (вже є на платі) Дистанційне вимкнення

Models heart, from the project README
From the project README

Main components on the Models heart

C16581C917079C84681C880752C89297C50506

Models heart bill of materials (BOM)

63 components, 28 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
C16581
TP4056
U1
1
C917079
DW01
U2
1
C84681
CH340C
U3
1
C880752
AMS1117-3.3
U4
1
C89297
ESP-12E
U5
1
C50506
DRV8833PWP
U6
4
C15127
AO3401A
Q1, Q4, Q5, Q8
1
C908265
FS8205
Q2
2
C62892
UMH3N
Q3, Q9
2
C699266
BC857BS
Q6, Q7
1
C2927038
USB_C_Plug
P1
1
C115362
SW_Push
SW1
1
C2286
LED
D1
1
C2290
LED
D2
1
C68955
BAS16TW
D3
7
C13585
10uF
C1, C2, C4, C5, C6, C10, C13
6
C913910
0.1uF
C3, C7, C8, C9, C11, C12
1
C49217
2.2uF
C14
1
0.1uF
C15
3
C21190
1k
R1, R2, R10
Show 8 more
QtyPartRefs
1
C22775
100
R3
10
C25804
10k
R4, R7, R8, R15, R16, R17, R18, R19 +2
2
C23179
470
R5, R6
1
NTC
R9
6
C25803
100k
R11, R12, R13, R14, R21, R25
2
C22961
220k
R20, R23
2
5k1
R26, R27
1
10k
R28

Models heart design files

The KiCad project lives in the KushlaVR/models-heart repository on GitHub; these links point at the commit this page was built from.

Models heart: common questions

What microcontroller does the Models heart use?

The Models heart is built around the C89297, from the ESP8266 family.

How big is the Models heart PCB?

The Models heart measures 29.9 × 32 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the Models heart?

63 components, from 28 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Models heart design files?

From the KushlaVR/models-heart repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Models heart design in my own project?

Yes, under the terms of its GPL-3.0 license, which KushlaVR chose for the repository.

Can I test firmware for the Models heart without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
