About the TypeC PCB
TypeC is an open source FPGA PCB design by mackieks, published on GitHub under the SHL-2.1 license. It is a 2-layer board measuring 17 × 21.3 mm, with 5 components from 5 distinct parts.
Its main chip is the XC3S200A-4VQG100C, from the FPGA family. Other key parts include the LW5912N23D and P25Q40H-UXH-IR. By type, the board carries 3 ICs and 2 connectors.
From the project
GCVideo DVI flex PCB for Nintendo Wii
Main components on the TypeC
TypeC bill of materials (BOM)
5 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LW5912N23D ESD204DQAR-ES Lewa Micro | Diodes_UDFN-10_1.0x2.5mm_P0.5mm | U1 |
| 1 | XC3S200A-4VQG100C ESD204DQAR-ES Xilinx / AMD | Diodes_UDFN-10_1.0x2.5mm_P0.5mm | U2 |
| 1 | P25Q40H-UXH-IR ESD204DQAR-ES PUYA | Diodes_UDFN-10_1.0x2.5mm_P0.5mm | U3 |
| 1 | 505278-1933 | 5052781933 | J2 |
| 1 | XUNPU HDMI-201 | 685119136923 | J3 |
TypeC design files
The KiCad project lives in the mackieks/fujiflex repository on GitHub; these links point at the commit this page was built from.
TypeC: common questions
What microcontroller does the TypeC use?
The TypeC is built around the XC3S200A-4VQG100C, from the FPGA family.
How big is the TypeC PCB?
The TypeC measures 17 × 21.3 mm, has 2 copper layers and is 0.8 mm thick.
How many components are on the TypeC?
5 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the TypeC design files?
From the mackieks/fujiflex repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the TypeC design in my own project?
It is published under SHL-2.1, which limits how it may be reused; read the license before building on it.
Can I test firmware for the TypeC without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug FPGA firmware against it before you order a PCB.
