OpenSpritzer-V2
About the OpenSpritzer-V2 PCB
OpenSpritzer-V2 is an open source ESP32 PCB design by MaximeZimmermann, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 200 × 100 mm, with 75 components from 51 distinct parts.
Its main chip is the ESP32-DEVKITC-32D, from the ESP32 family. Other key parts include the LM2596T-3.3, SN74HC14N, VO615A and ST7789V Screen. By type, the board carries 25 resistors, 20 capacitors, 8 diodes, 5 ICs, 5 connectors and 4 inductors.
From the project
This project is licensed under the GNU General Public License v3.0 The hardware is licensed under the CERN OHL v1.2
Main components on the OpenSpritzer-V2
OpenSpritzer-V2 bill of materials (BOM)
75 components, 51 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LM2596T-3.3 | TO-220-5_P3.4x3.7mm_StaggerOdd_Lead3.8mm_Vertical | U1 |
| 1 | SN74HC14N | DIP-14_W7.62mm_Socket_LongPads | U2 |
| 1 | VO615A | DIP-4_W7.62mm_Socket_LongPads | U3 |
| 1 | ESP32-DEVKITC-32D | MODULE_ESP32-DEVKITC-32D | U4 |
| 1 | ST7789V Screen | JST_XH_B8B-XH-A_1x08_P2.50mm_Vertical | U5 |
| 1 | 2N5089 | TO-92L_Inline_Wide | Q1 |
| 2 | Screw_Terminal | TerminalBlock_Phoenix_MKDS-1,5-2-5.08_1x02_P5.08mm_Horizontal | J1, J2 |
| 1 | to Solenoid | JST_XH_B3B-XH-A_1x03_P2.50mm_Vertical | J3 |
| 1 | BNC Pedal | BNC_Socket_TYCO-AMP_LargePads | J4 |
| 1 | BNC TTL | BNC_Socket_TYCO-AMP_LargePads | J5 |
| 1 | Fuse | FUSE_65600001009_LTF | F1 |
| 1 | IRM-30-24 | Converter_ACDC_MeanWell_IRM-10-xx_THT | PS1 |
| 1 | Varistor | C_Disc_D11.0mm_W5.0mm_P5.00mm | RV1 |
| 1 | SW_SPST_LED | TerminalBlock_Phoenix_MKDS-1,5-3-5.08_1x03_P5.08mm_Horizontal | SW1 |
| 1 | Rotary Encoder | PinHeader_1x05_P2.54mm_Vertical | SW2 |
| 1 | SW_Push_DPDT | maxi_DPDT_Angled | SW3 |
| 1 | Thermistor_NTC | C_Disc_D11.0mm_W5.0mm_P5.00mm | TH1 |
| 1 | SMBJ33A hongjiacheng | D_SMB | D1 |
| 1 | P6SKE6.8A hongjiacheng | D_SMB | D2 |
| 1 | 1N5822 | D_DO-201AD_P15.24mm_Horizontal | D3 |
Show 31 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | SMAJ5.0A | D_SMA | D4 |
| 1 | 1N4148 | D_DO-35_SOD27_P7.62mm_Horizontal | D5 |
| 1 | Spritz LED | JST_XH_B2B-XH-A_1x02_P2.50mm_Vertical | D6 |
| 1 | LED Pedal | LED_D3.0mm | D7 |
| 1 | LED TTL | LED_D3.0mm | D8 |
| 2 | FerriteBead | D_5W_P12.70mm_Horizontal | FB1, FB2 |
| 1 | 33μH | L_Radial_D6.0mm_P4.00mm | L1 |
| 1 | 2.2μH | L_Radial_D6.0mm_P4.00mm | L2 |
| 1 | 470μF | CP_Radial_D6.3mm_P2.50mm | C1 |
| 6 | 0.1μF | C_Disc_D4.7mm_W2.5mm_P5.00mm | C2, C6, C10, C15, C17, C20 |
| 1 | 680μF | CP_Radial_D6.3mm_P2.50mm | C3 |
| 1 | 100μF | CP_Radial_D6.3mm_P2.50mm | C4 |
| 1 | 1μF | C_Disc_D4.7mm_W2.5mm_P5.00mm | C5 |
| 1 | 220μF | CP_Radial_D6.3mm_P2.50mm | C7 |
| 1 | 10μF | CP_Radial_D6.3mm_P2.50mm | C8 |
| 1 | 47μF | CP_Radial_D6.3mm_P2.50mm | C9 |
| 1 | 100pF | C_Disc_D4.7mm_W2.5mm_P5.00mm | C11 |
| 1 | 22μF | CP_Radial_D6.3mm_P2.50mm | C12 |
| 2 | 100nF | C_Disc_D4.7mm_W2.5mm_P5.00mm | C13, C14 |
| 1 | 4.7μF | CP_Radial_D6.3mm_P2.50mm | C16 |
| 2 | 10nF | C_Disc_D4.7mm_W2.5mm_P5.00mm | C18, C19 |
| 4 | 1k | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R1, R12, R20, R21 |
| 2 | 100k | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R2, R11 |
| 3 | 100 | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R3, R22, R23 |
| 7 | 10k | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R4, R7, R13, R15, R17, R24, R25 |
| 1 | 470 | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R5 |
| 1 | 4.7k | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R6 |
| 2 | 22 | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R8, R9 |
| 1 | 47k | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R10 |
| 3 | 150 | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R14, R16, R18 |
| 1 | 220 | R_Axial_DIN0309_L9.0mm_D3.2mm_P15.24mm_Horizontal | R19 |
OpenSpritzer-V2 design files
The KiCad project lives in the MaximeZimmermann/OpenSpritzer-V2 repository on GitHub; these links point at the commit this page was built from.
- LayoutPCB/OpenSpritzer2.kicad_pcb
- SchematicPCB/OpenSpritzer2.kicad_sch
- BOMBOM.csv
OpenSpritzer-V2: common questions
What microcontroller does the OpenSpritzer-V2 use?
The OpenSpritzer-V2 is built around the ESP32-DEVKITC-32D, from the ESP32 family.
How big is the OpenSpritzer-V2 PCB?
The OpenSpritzer-V2 measures 200 × 100 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the OpenSpritzer-V2?
75 components, from 51 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the OpenSpritzer-V2 design files?
From the MaximeZimmermann/OpenSpritzer-V2 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the OpenSpritzer-V2 design in my own project?
Yes, under the terms of its GPL-3.0 license, which MaximeZimmermann chose for the repository.
Can I test firmware for the OpenSpritzer-V2 without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
