timohueser·OpenBikeComputer·hardware/projects/OBC_PCB/OBC_PCB.kicad_pcb

OpenBikeComputer PCB layout, top view — open source Nordic nRF board by timohueser
Simulate this board

About the OpenBikeComputer PCB

OpenBikeComputer is an open source Nordic nRF PCB design by timohueser, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 37 × 61 mm, with 10 components from 10 distinct parts.

Its main chip is the nRF54LM20A-PAXX, from the Nordic nRF family. Other key parts include the MAX-M10S, NPM1300-CAAA-R, BMA400, BMM350 and BMP581. By type, the board carries 6 ICs, 3 connectors and 1 antenna.

It belongs with the iot & wireless designs in this gallery.

From the project

Open source Bikecomputer with a focus on exploration and adventure.

An open-source GPS computer for bikepacking.

Live browser demo · Documentation · Contributing

OpenBikeComputer is a fully open-source, bikepacking-focused GPS cycling computer. The main features and capabilities we are aiming for are the following (roughly in order of importance): - Reliable and simple map-based tracking and navigation - Uploading a route from the companion app should work every time (no BLE connection issues, no unreasonably low limit on point count in GPX files etc.) - No subscriptions or accounts required for any of the features of the device - Long battery life, ideally…

OpenBikeComputer, from the project README
From the project README

Main components on the OpenBikeComputer

MAX-M10SNPM1300-CAAA-RBMA400BMM350BMP581nRF54LM20A-PAXX

OpenBikeComputer bill of materials (BOM)

10 components, 10 distinct parts.

QtyPartRefs
1
MAX-M10S
U1
1
NPM1300-CAAA-R
Nordic Semiconductor
U2
1
BMA400
Bosch Sensortec
U3
1
BMM350
Bosch Sensortec
U4
1
BMP581
Bosch Sensortec
U5
1
nRF54LM20A-PAXX
Nordic Semiconductor
U6
1
503566-2102
Molex
J1
1
DM3CS-SF
Hirose
J2
1
USB4720-03-A
GCT
J3
1
SGGP.12.4.A.02
Taoglas
ANT1

OpenBikeComputer design files

The KiCad project lives in the timohueser/OpenBikeComputer repository on GitHub; these links point at the commit this page was built from.

OpenBikeComputer: common questions

What microcontroller does the OpenBikeComputer use?

The OpenBikeComputer is built around the nRF54LM20A-PAXX, from the Nordic nRF family.

How big is the OpenBikeComputer PCB?

The OpenBikeComputer measures 37 × 61 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the OpenBikeComputer?

10 components, from 10 distinct parts. The full bill of materials is listed on this page.

Where can I download the OpenBikeComputer design files?

From the timohueser/OpenBikeComputer repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the OpenBikeComputer design in my own project?

Yes, under the terms of its GPL-3.0 license, which timohueser chose for the repository.

Can I test firmware for the OpenBikeComputer without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Nordic nRF firmware against it before you order a PCB.
