SatelliteNode-Switch

tokai-student-rocket-project·Gen6-GSE-Elec·KiCad/SatelliteNode/SatelliteNode-Switch.kicad_pcb

SatelliteNode-Switch PCB layout, top view — open source board by tokai-student-rocket-project
Simulate this board

About the SatelliteNode-Switch PCB

SatelliteNode-Switch is an open source PCB design by tokai-student-rocket-project, published on GitHub under the MIT license. It is a 2-layer board measuring 30 × 30 mm, with 7 components from 6 distinct parts.

By type, the board carries 2 diodes, 2 resistors, 1 transistor, 1 connector and 1 capacitor.

It belongs with the rf & radio designs in this gallery.

From the project

第6世代自動GSE電装系

2025年3月8日，H-60号機打上げ実験にて運用をし正常に動作したことを確認しました．

platform.iniはPlatformIOを使用するための設定ファイルです．外部ライブラリがインストールされていなくてもこのplatform.iniファイルに記載があれば自動的にインストールしてくるため環境構築を行いやすくなり，とても便利です．参照：公式

platform.iniファイルにはセクションがあり，それぞれに対してKeyとValueのペアがあります．

platform = atmelavr > 使用するマイコンに合わせています．参照：公式

board = ATmega2560 > 使用するマイコンが持つ固有の値を入れています．参照：公式

framework = arduino > 使用したいフレームワークを指定しています．参照：公式

SatelliteNode-Switch, from the project README
From the project README

SatelliteNode-Switch bill of materials (BOM)

7 components, 6 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
TJ8S06M3L
DTC123EU3
Q1
1
DF51A-4P-2DS
J1
1
GS1010FL
GREEN
D1
1
RED
D2
1
15PF
0.1uF
C1
2
1KR
330R
R1, R2

SatelliteNode-Switch design files

The KiCad project lives in the tokai-student-rocket-project/Gen6-GSE-Elec repository on GitHub; these links point at the commit this page was built from.

SatelliteNode-Switch: common questions

How big is the SatelliteNode-Switch PCB?

The SatelliteNode-Switch measures 30 × 30 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the SatelliteNode-Switch?

7 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the SatelliteNode-Switch design files?

From the tokai-student-rocket-project/Gen6-GSE-Elec repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the SatelliteNode-Switch design in my own project?

Yes, under the terms of its MIT license, which tokai-student-rocket-project chose for the repository.
