Main board layout, top view — open source board by TUDSSL
Simulate this board

About the Main board

Main board is an open source PCB design by TUDSSL, published on GitHub under the MIT license. It is a 2-layer board measuring 98 × 128 mm, with 117 components from 55 distinct parts.

Other key parts include the BQ25570, SX1503, TPS610995DRV, Apollo-3-module and TPS79301-EP. By type, the board carries 33 resistors, 29 capacitors, 15 connectors, 12 diodes, 9 switches and 7 test points.

It belongs with the retro computing and power & battery designs in this gallery.

From the project

Source code repository for ENGAGE: Battery-Free Game Boy

This is the official public repository for ENGAGE: the battery-free gaming console.

Battery-free devices can make phone calls, facilitate machine learning, or even track eyes, but immersive interactive experience without batteries has not been explored so far. In this project we focus on this ignored part of the battery-free device ecosystem. We explore how reactive and user-centric applications, mobile gaming in particular, can also be battery-free.

Main board, from the project README
From the project README

Main components on the Main board

BQ25570SX1503TPS610995DRVApollo-3-moduleTPS79301-EP

Main board bill of materials (BOM)

117 components, 55 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
BQ25570
U1
2
SX1503
U2, U3
1
TPS610995DRV
U4
1
Apollo-3-module
U5
1
TPS79301-EP
U7
2
Conn_01x02
J1, J2
1
52745-1097
J3
1
GB_CART_CON
J9
1
Conn_02x02_Odd_Even
J12
3
Conn_01x03
J14, J19, J20
1
Conn_02x03_Odd_Even
J15
1
Conn_01x02
J17
1
Conn_02x05_Odd_Even
J18
1
USB_B_Micro
J21
3
Screw_Terminal_01x02
J22, J23, J24
1
MF-USMF010
F1
2
eC_Registration
H8, H9
1
TUD_SSL_QR
S1
2
SW_Push
SW1, SW2
6
EH_SWITCH
SW4, SW5, SW6, SW7, SW8, SW9
Show 35 more
QtyPartRefs
7
TestPoint
TP1, TP2, TP3, TP4, TP5, TP6, TP7
1
SZMM3Z5V1ST1G
D1
6
NSR1030QMUTWG
D2, D3, D4, D5, D6, D7
3
BAS40-02V-V-G-08
D8, D9, D12
1
3SMAJ5919B-TP
D10
1
LED
D11
1
744031220
L1
1
LQH2HPN2R2MJRL
L2
1
744029100
L3
2
DNP
C1, C22
3
10nF
C2, C19, C26
6
100nF
C3, C8, C9, C13, C17, C29
3
DNP
C4, C5, C20
1
4.7uF
C6
5
10uF
C7, C10, C24, C25, C28
4
1uF
C11, C12, C14, C15
1
DNP
C16
1
4.7uF
C18
1
100uF
C21
1
22uF
C23
1
15pF
C27
2
2M
R1, R19
8
DNP
R2, R3, R4, R5, R6, R7, R8, R9
11
1M
R10, R11, R18, R27, R28, R29, R30, R31 +3
1
8.2M
R13
2
4.7M
R14, R23
1
7.5M
R15
1
5.1M
R16
1
3.6M
R17
1
6.2M
R20
1
3M
R21
1
3.9M
R22
1
82k
R24
1
30.1k
R25
1
560
R26

Main board design files

The KiCad project lives in the TUDSSL/ENGAGE repository on GitHub; these links point at the commit this page was built from.
