Smart fan
About the Smart fan PCB
Smart fan is an open source ESP8266 PCB design by VGCH, published on GitHub. It is a 2-layer board measuring 40 × 32 mm, with 41 components from 32 distinct parts.
Its main chip is the ESP-12F, from the ESP8266 family. Other key parts include the LNK306G, PC817 and MOC3052M. By type, the board carries 17 resistors, 6 diodes, 6 capacitors, 5 connectors, 4 ICs and 1 transistor.
From the project
Smart controller for fan
Если данный проект был вам полезен, то вы можете задонатить разработчику на кофе.
Main components on the Smart fan
Smart fan bill of materials (BOM)
41 components, 32 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LNK306G | PowerIntegrations_SMD-8B | U1 |
| 1 | PC817 | Panasonic_APV-AQY_SSOP-4_4.45x2.65mm_P1.27mm | U2 |
| 1 | MOC3052M | DIP-6_W7.62mm | U3 |
| 1 | ESP-12F | ESP-12E | U4 |
| 1 | BT136-600 | TO-252-2 | Q1 |
| 1 | input 240V AC | TerminalBlock_bornier-2_P5.08mm | J1 |
| 1 | FAN | TerminalBlock_bornier-2_P5.08mm | J2 |
| 1 | Сигнал управления (Signal On/Off FAN) | TerminalBlock_bornier-2_P5.08mm | J3 |
| 1 | Выход | TerminalBlock_bornier-3_P5.08mm | J4 |
| 1 | ~ | TerminalBlock_bornier-5_P5.08mm | J6 |
| 1 | Buzzer | MagneticBuzzer_PUI_AT-0927-TT-6-R | BZ1 |
| 1 | RMB4S | TO-269AA | D1 |
| 2 | UF4005 US1J | D_MELF | D2, D4 |
| 1 | 1N4007W | D_MELF | D3 |
| 2 | LED | LED_1206_3216Metric | D5, D6 |
| 1 | 470mH | L_Axial_L9.5mm_D4.0mm_P2.54mm_Vertical_Fastron_SMCC | L1 |
| 1 | 10uF 400V | CP_Radial_D8.0mm_P3.80mm | C1 |
| 1 | 100n | C_1206_3216Metric | C2 |
| 1 | 10uF 16V | CP_Elec_5x5.4 | C3 |
| 2 | 100uF 16V | CP_Elec_5x5.4 | C4, C5 |
Show 12 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 10n | C_1206_3216Metric | C6 |
| 1 | 2k | R_0805_2012Metric | R1 |
| 2 | 10 | R_1206_3216Metric | R2, R12 |
| 2 | 30k | R_1206_3216Metric | R3, R4 |
| 1 | 2.2k | R_0805_2012Metric | R5 |
| 1 | 1.5k | R_0805_2012Metric | R6 |
| 1 | 600 | R_0805_2012Metric | R7 |
| 1 | 330 | R_0805_2012Metric | R8 |
| 4 | 1k | R_0805_2012Metric | R9, R10, R11, R13 |
| 2 | 470 | R_0805_2012Metric | R14, R15 |
| 1 | 4.7k | R_0805_2012Metric | R16 |
| 1 | 39 | R_1206_3216Metric | R17 |
Smart fan design files
The KiCad project lives in the VGCH/smart_fan repository on GitHub; these links point at the commit this page was built from.
- Layoutfan_reg/fan_reg.kicad_pcb
- Schematicfan_reg/fan_reg.kicad_sch
Smart fan: common questions
What microcontroller does the Smart fan use?
The Smart fan is built around the ESP-12F, from the ESP8266 family.
How big is the Smart fan PCB?
The Smart fan measures 40 × 32 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Smart fan?
41 components, from 32 distinct parts. The full bill of materials is listed on this page.
Where can I download the Smart fan design files?
From the VGCH/smart_fan repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Smart fan design in my own project?
The repository has no license, so all rights stay with VGCH. Use it as a reference, and ask the author before reusing the design.
Can I test firmware for the Smart fan without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
