Main board

ARTS-Laboratory·Sensor-Package-Access-Hub·system_development/V0.3.1/Water height sensor design files/V0.5.1/EDA/main_board/main_board.kicad_pcb

Main board layout, top view — open source AVR/Arduino board by ARTS-Laboratory
Simulate this board

About the Main board

Main board is an open source AVR/Arduino PCB design by ARTS-Laboratory, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 40.6 × 82.6 mm, with 32 components from 25 distinct parts.

Its main chip is the Arduino_Nano_v2.x-MCU_Module, from the AVR/Arduino family. Other key parts include the HX-2S-JH10, DS3231M, INA219AxD, BME280_module and KA78M05_TO252. By type, the board carries 11 resistors, 6 capacitors, 5 ICs, 3 connectors, 2 diodes and 1 module.

It belongs with the sensors designs in this gallery.

From the project

An access hub for communicating with the lab's sensor packages over short-range RF

Main board, from the project README
From the project README

Main components on the Main board

HX-2S-JH10DS3231MINA219AxDBME280_moduleKA78M05_TO252Arduino_Nano_v2.x-MCU_Module

Main board bill of materials (BOM)

32 components, 25 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
HX-2S-JH10
U1
1
DS3231M
U2
1
INA219AxD
U3
1
BME280_module
U4
1
KA78M05_TO252
U5
1
Arduino_Nano_v2.x-MCU_Module
A1
1
B3B-XH-A_LF__SN_
J1
1
Conn_01x02_Pin
J2
1
SD card socket
P1
1
Battery_Cell
BT1
1
SW_Wuerth_450301014042
SW1
1
HCSR04
Ultrasonic_sensor1
1
nRF24L01+
nRF24L01+1
1
D_Schottky
D1
1
LED
D2
3
0.1uF
C1, C2, C4
1
22uF
C3
1
10uF
C5
1
0.1uF
C6
1
1k
R1
Show 5 more
QtyPartRefs
1
0.1
R2
2
4.7k
R3, R4
1
4.7k
R5
3
2K
R6, R8, R10
3
1K
R7, R9, R11

Main board design files

The KiCad project lives in the ARTS-Laboratory/Sensor-Package-Access-Hub repository on GitHub; these links point at the commit this page was built from.

Main board: common questions

What microcontroller does the Main board use?

The Main board is built around the Arduino_Nano_v2.x-MCU_Module, from the AVR/Arduino family.

How big is the Main board?

The Main board measures 40.6 × 82.6 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Main board?

32 components, from 25 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Main board design files?

From the ARTS-Laboratory/Sensor-Package-Access-Hub repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Main board design in my own project?

Yes, under the terms of its CC-BY-SA-4.0 license, which ARTS-Laboratory chose for the repository.

Can I test firmware for the Main board without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
